Sharp LC-32DH77E Service Manual

LC-32/42/46DH77E/RU/S
21
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] CABINET PARTS (LC-42DH77E/RU/S)
1 CCABAC219WJ03 N P Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - Bottom Dec Ass'y
1-2-1 Not Available - N - Bottom Dec (A) Ass'y
1-2-2 Not Available - N - Bottom Dec (B) Ass'y
1-2-3 XEBSN40P10000 AB J Screw, x6 (DEC-A/B FIX)
1-3 Not Available - - LED Decoration
1-4 XEBSN40P10000 AB J Screw, x9 (DEC ASSY FIX)
2 CCABBB425WJ01 BM N P Back Cabinet Ass'y
2-1 Not Available - N - Back Cabinet
2-2 Not Available - N - Terminal Label
3 CCOVAC952WJ04 AL P Control Cover Ass'y
3-1 Not Available - N - Control Cover
3-2 Not Available - N - Control Label
4 CANGKC098WJ01 AH N P Vesa Angle Top Ass'y, x2
4-1 Not Available - N - Base Angle Top
4-2 Not Available - N - Vesa Angle
4-3 XHPS730P06WS0 AA J Screw
5 CANGKC099WJ01 AN N P Vesa Angle Bottom Ass'y, x2
5-1 Not Available - N - Base Angle Bottom
5-2 Not Available - N - Vesa Angle
5-3 XHPS730P06WS0 AA J Screw
6 CCOVAD246WJ02 AQ N P Side AV Cover Ass'y
6-1 Not Available - N - Side AV Cover
6-2 Not Available - N - Side AV Label
7 GCOVAD248WJ1A AK P Bottom Cover
8 LHLDWA048WJKZ AB J Wire Holder, x2 (SP_L)
9 LHLDWA143WJKZ AC J Wire Holder, x2 (CABLE)
10 LHLDZA934WJKZ AB J Power PWB Holder, x5
11 LX-BZA170WJF9 AC P Screw, x2 (Vesa Boss)
12 NSFTZA237WJFN AC J Shaft, x4 (D-SUB)
13 PSHEPA543WJZZ AA N P Sheet For Vesa, x2
14 PSLDMB539WJFW AP N P Full Shield
15 PSPAZC237WJKZ AH N P
Cooling Sheet, x2
16 QCNW-H951WJQZ AF N P Connecting Cord (KM)
17 QCNW-H852WJQZ AE N P Connecting Cord (LA)
18 QCNW-H853WJQZ AG N P Connecting Cord (LB1)
19 QCNW-H854WJQZ AE N P Connecting Cord (LB2)
20 QCNW-H856WJQZ AF N P Connecting Cord (LP)
21 QCNW-H857WJQZ BA N P Connecting Cord (LW)
22 QCNW-H858WJQZ AN N P Connecting Cord (PD)
23 QCNW-H950WJQZ AE N P Connecting Cord (PL)
24 QCNW-H848WJQZ AH P Connecting Cord (RA)
25 QCNW-J551WJPZ AK N P Connecting Cord (SP)
26 QEARPA339WJFW AB N P Earth Plate
29 RSP-ZA421WJZZ AS N P Speaker (L)
30 RSP-ZA422WJZZ AS N P Speaker (R)
32 XBBS730P04000 AA J Screw (TUN/SHIELD)
33 XBPS830P06000 AA J Screw, x3 (HDMI)
34 XEBS930P08000 AA J Screw (21PIN)
35 XEBS940P16000 AB J Screw, x7 (CAB-B FIX)
36 XEBSN40P10000 AB J Screw, x8 (LCD-PANEL)
37 XHPS730P06WS0 AA J Screw, x30 (ANG/PWB FIX)
38 XHPS730P10WS0 AA P Screw, x5 (CAB-B)
39 TLABNC117WJZZ AB P Model Label
40 TLABZB406WJZZ AC P EU ECO Label (LC-42DH77E/S)
