LC-32/42/46DH77E/RU/S
23
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[9] LCD PANEL MODULE ASSEMBLY (LC-42DH77E/RU/S)
1 R1LK420D3LW80Y DN N P 42" LCD Panel Module
2 Not Available - - BEZEL Ass'y
3 CCHSMA552WJ01 J Back Light Chassis Ass'y
4 LHLDZA963WJKZ AB J Holder, x4
5 RLMPLA039WJN1 AQ J Lamp, x18
6 QSOCFA005WJZZ AD J Socket, x18
7 CHLDZB347WJ01 AT J Lamp Holder Unit
8 CHLDZB348WJ01 AT J Lamp Holder Unit
9 PCOVUA141WJZZ AZ J Diffusion Plate
10 PSHEPA872WJZZ AX J Lens Sheet
11 CHLDZB335WJ01 J Panel Chassis unit
12 CHLDZB337WJ01 J Panel Chassis unit
13 CHLDZB381WJ01 J Sheet Holder Unit, x2
14 CSLDMB528WJ01 J LCD Control Unit Cover
15 PCOVWA036WJKZ AM J Cover
16 PCOVWA037WJKZ AL J Cover
17 RUNTKA534WJZZ BP J INVERTER Unit
18 RUNTKA536WJZZ AP J GND-PWB
19 RUNTKA537WJZZ AP J GND-PWB
20 QPWBM0567TPZZ AG J SC-FPC
21 QPWBM0570TPZZ AG J SC-FPC
22 CPWBX4023TPXE BW J LCD Control Unit
23 PSHEP2941TPZZ J Heat Radiation Sheet (for LCD Control unit)
24 RCORFA061WJZZ AG J Ferrite Core, x2
25 XHPS830P06WS0 AA J Screw, x9 (for fixing Inverter Unit x3, for fixing Cover x6)
26 LX-HZA039WJF7 AB J Screw, x16 (for fixing Bezel Ass'y)
27 LX-HZA047WJF7 AB J Screw, x2 (for fixing Bezel Ass'y)
28 LX-HZA046WJF7 AB J Screw, x4 (for fixing GND-PWB)
29 LX-HZA045WJF7 AB J Screw, x6 (for fixing LCD Control unit)
30 XHPS730P06WS0 AA J Screw, x4 (for fixing LCD Control unit Cover)
