LC-32/42/46DH77E/RU/S
27
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[11] LCD PANEL MODULE ASSEMBLY (LC-46DH77E/RU/S)
1 R1LK460D3LW80Y DX N P 46" LCD Panel Module
2 Not Available - - BEZEL Ass'y
3 CCHSMA553WJ01 J Back Light Chassis Ass'y
4 LHLDZA963WJKZ AB J Holder, x4
5 RLMPLA038WJN1 AR J Lamp, x18
6 QSOCFA002WJZZ AD J Socket, x18
7 CHLDZB349WJ01 AU J Lamp Holder Unit
8 CHLDZB350WJ01 AU J Lamp Holder Unit
9 PCOVUA113WJZZ BA J Diffusion Plate
10 PSHEPA873WJZZ AX J Lens Sheet
11 CHLDZB383WJ01 J Panel Chassis unit
12 CHLDZB385WJ01 J Panel Chassis unit
13 CHLDZB382WJ01 J Sheet Holder Unit, x2
14 CSLDMB528WJ01 J LCD Control Unit Cover
15 PCOVWA038WJKZ AM J Cover
16 PCOVWA039WJKZ AM J Cover
17 RUNTKA538WJZZ BF J INVERTER Unit
18 RUNTKA539WJZZ BF J INVERTER Unit
19 RUNTKA540WJZZ AP J GND-PWB
20 RUNTKA541WJZZ AP J GND-PWB
21 QPWBM0782TPZZ AG J FPC
22 QPWBM0783TPZZ AG J FPC
23 CPWBX4151TPXA J LCD Control Unit
24 PSHEP2941TPZZ J Heat Radiation Sheet (for LCD Control unit)
25 RCORFA061WJZZ AG J Ferrite Core, x2
26 XHPS830P06WS0 AA J Screw, x10 (for fixing Inverter Unit x4, for fixing Cover x6)
27 LX-HZA039WJF7 AB J Screw, x14 (for fixing Bezel Ass'y)
28 LX-HZA047WJF7 AB J Screw, x2 (for fixing Bezel Ass'y)
29 LX-HZA046WJF7 AB J Screw, x4 (for fixing GND-PWB)
30 LX-HZA045WJF7 AB J Screw, x6 (for fixing LCD Control unit)
31 XHPS730P06WS0 AA J Screw, x4 (for fixing LCD Control unit Cover)
To Next Page
