1 Confirm that there are eight screws with the stand unit.
2 Attach the supporting post for the stand unit onto the base using the four screws with the screw driver (supplied)
as shown.
3 Inserting the stand.
Insert the stand into the openings on the bottom of the TV (Hold the stand so it will not drop from the edge
of the base area).
Insert and tighten the four screws into the four holes on the rear of the TV.
NOTE
• To detach the stand unit, perform the above steps in reverse order.
Remote control unit
(g1)
AC cord (g1)
• Operation manual (This publication)
• “AA” size zinc-carbon battery (g2)
Product shape varies in
some countries.
Preparation
Supplied accessories
Attaching the stand unit
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work, spread cushioning over the surface on wich you will be laying the TV. This will prevent it
from being damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
Optional accessory
The listed optional accessories are available for this
LCD colour TV. Please purchase them at your nearest
shop.
• Additional optional accessories may be available in the
near future. When purchasing, please read the newest
catalogue for compatibility and check the availability.
No. Part name Part number
1
Wall mount bracket
AN-37AG5
• Stand unit (x1)
Supporting
post
Soft cushion
5
1
2
To Next Page
