Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
RUNTKA082WJZZ (LC-37G4U/G4D)
INVERTER-1 GND Unit(Continued)
RUNTKA083WJZZ (LC-37G4U/G4D)
INVERTER-2 GND Unit
P7605 QCNCM1821SNEZ J Plug, 8Pin, 1717823-1 AD
P7606 QCNCM1796SNEZ J Plug, 6Pin, S8B-PASK-2 AD
P7607 QCNCM1824SNEZ J Plug, 8Pin, 06PL-FJ AD
LUG7601 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7602 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7603 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7604 QTAND1019SNEZ J GND Lug, SD01138-21 AD
TRANSISTORS
Q7651 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7652 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7653 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7654 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7655 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7656 VSUM6K1N///-1 J UM6K1N, MOSFET AD
DIODES
D7651 VHDDAN217U/-1 J DAN217U AC
D7652 VHDDAN217U/-1 J DAN217U AC
D7653 VHDDAN217U/-1 J DAN217U AC
D7654 VHDDAN217U/-1 J DAN217U AC
D7655 VHDDAN217U/-1 J DAN217U AC
D7656 VHDDAN217U/-1 J DAN217U AC
D7657 VHDDAN217U/-1 J DAN217U AC
D7658 VHDDAN217U/-1 J DAN217U AC
CAPACITORS
C7651 VCKYTQ1EB105K J 1 25V Ceramic AC
C7652 VCKYTQ1EB105K J 1 25V Ceramic AC
C7653 VCKYTQ1EB105K J 1 25V Ceramic AC
C7654 VCKYTQ1EB105K J 1 25V Ceramic AC
C7655 VCKYTQ1EB105K J 1 25V Ceramic AC
C7656 VCKYTQ1EB105K J 1 25V Ceramic AC
RESISTORS
R7651 VRS-CY1JD104F J 100K1/10W Metal Oxide AA
R7652 VRS-CY1JD104F J 100K1/10W Metal Oxide AA
R7653 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7654 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7655 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7656 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7657 VRS-CY1JD104F J 100K1/10W Metal Oxide AA
R7658 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7659 VRS-CY1JD104F J 100K1/10W Metal Oxide AA
R7660 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7661 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7662 VRS-CY1JD104F J 100K1/10W Metal Oxide AA
R7663 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7664 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7665 VRS-CY1JD104F J 100K1/10W Metal Oxide AA
R7666 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7667 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7668 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7670 VRS-CY1JD132F J 1.3K 1/10W Metal Oxide AA
R7671 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7673 VRS-CY1JD132F J 1.3K 1/10W Metal Oxide AA
R7674 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7675 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7676 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7677 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7678 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
THERMISTOR
TH7651 VHH18XH103J03 J NCP18XH103J03RB AC
MISCELLANEOUS PARTS
P7651 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7652 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7653 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7654 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7655 QCNCM1825SNEZ J Plug, 6Pin, 06R-FJ AD
LUG7651 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7652 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7653 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7654 QTAND1019SNEZ J GND Lug, SD01138-21 AD
