Sharp LC-32G4U User Manual

122
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
RUNTKA081WJZZ (LC-37G4U/G4D)
INVERTER-2 Unit(Continued)
RUNTKA082WJZZ (LC-37G4U/G4D)
INVERTER-1 GND Unit
C7430 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7431 VCKYCY1CB473K J 0.047 16V Ceramic AA
C7432 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7433 VCKYTV1AB225K J 2.2 10V Ceramic AC
C7434 VCKYTV1AB225K J 2.2 10V Ceramic AC
C7435 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7436 VCKYCY1CB104K J 0.1 16V Ceramic AB
C7438 VCCCCY1HH331J J 330p 50V Ceramic AA
C7439 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7440 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7441 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7442 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7444 RCE1E337KZEBC J 330 25V Electrolytic AE
RESISTORS
R7401 VRS-CY1JD333F J 33K 1/10W Metal Oxide AA
R7402 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7403 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7404 VRS-CY1JD333F J 33K 1/10W Metal Oxide AA
R7405 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7406 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7407 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7408 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7409 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7411 VRS-CY1JD112F J 1.1K 1/10W Metal Oxide AA
R7412 VRS-CY1JD101F J 100 1/10W Metal Oxide AA
R7415 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7416 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7418 VRS-CY1JD753F J 75K 1/10W Metal Oxide AA
R7419 VRS-CY1JD363F J 36K 1/10W Metal Oxide AA
R7421 VRS-CY1JD102F J 1K 1/10W Metal Oxide AA
R7422 VRS-CY1JD112F J 1.1K 1/10W Metal Oxide AA
R7426 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7427 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7428 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7429 VRS-CY1JD102F J 1K 1/10W Metal Oxide AA
R7430 VRS-CY1JD101J J 100 1/10W Metal Oxide AA
R7431 VRS-CY1JD101J J 100 1/10W Metal Oxide AA
R7432 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7435 VRS-CY1JD101J J 100 1/10W Metal Oxide AA
R7436 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7438 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7440 VRS-CY1JD473F J 47K 1/10W Metal Oxide AA
R7441 VRS-CY1JD513F J 51K 1/10W Metal Oxide AA
R7442 VRS-CY1JD513F J 51K 1/10W Metal Oxide AA
R7443 VRS-CY1JD753F J 75K 1/10W Metal Oxide AA
R7444 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7445 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7450 VRS-TP2BD000J J 0 1/4W AA
R7451 VRS-TP2BD000J J 0 1/4W AA
R7452 VRS-TP2BD000J J 0 1/4W AA
R7453 VRS-TP2BD000J J 0 1/4W AA
R7454 VRS-TP2BD000J J 0 1/4W AA
R7455 VRS-TP2BD000J J 0 1/4W AA
R7456 VRS-TP2BD000J J 0 1/4W AA
R7457 VRS-TP2BD000J J 0 1/4W AA
FUSES AND FUSE HOLDERS
åF7401 QFS-A1153SNEZ J Fuse, TLCN4 10A/250V AF
FH7401 QFSHA1012SNEZ J Fuse Holder, H-0017-2 AD
FH7402 QFSHA1012SNEZ J Fuse Holder, H-0017-2 AD
MISCELLANEOUS PARTS
P7401 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7402 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7403 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7404 QCNCM1775SNEZ J Plug, 2Pin, B2PS-VH AD
P7405 QCNCM1827SNEZ J Plug, 12Pin, 12R-FJ AD
P7406 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
LUG7401 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7402 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7403 QTAND1019SNEZ J GND Lug, SD01138-21 AD
TRANSISTORS
Q7601 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7602 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7603 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7604 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7605 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7606 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7607 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7608 VSUM6K1N///-1 J UM6K1N, MOSFET AD
DIODES
D7601 VHDDAN217U/-1 J DAN217U AC
D7602 VHDDAN217U/-1 J DAN217U AC
D7603 VHDDAN217U/-1 J DAN217U AC
D7604 VHDDAN217U/-1 J DAN217U AC
D7605 VHDDAN217U/-1 J DAN217U AC
D7606 VHDDAN217U/-1 J DAN217U AC
D7607 VHDDAN217U/-1 J DAN217U AC
D7608 VHDDAN217U/-1 J DAN217U AC
D7609 VHDDAN217U/-1 J DAN217U AC
D7610 VHDDAN217U/-1 J DAN217U AC
CAPACITORS
C7601 VCKYTQ1EB105K J 1 25V Ceramic AC
C7602 VCKYTQ1EB105K J 1 25V Ceramic AC
C7603 VCKYTQ1EB105K J 1 25V Ceramic AC
C7604 VCKYTQ1EB105K J 1 25V Ceramic AC
C7605 VCKYTQ1EB105K J 1 25V Ceramic AC
C7606 VCKYTQ1EB105K J 1 25V Ceramic AC
C7607 VCKYTQ1EB105K J 1 25V Ceramic AC
C7609 VCKYTQ1EB105K J 1 25V Ceramic AC
RESISTORS
R7601 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7602 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7603 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7604 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7605 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7606 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7607 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7608 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7609 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7610 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7611 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7612 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7613 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7614 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7615 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7616 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7617 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7618 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7619 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7620 VRS-CY1JD104F J 100K 1/10W Metal Oxide AA
R7621 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7622 VRS-CY1JD105J J 1M 1/10W Metal Oxide AA
R7623 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7625 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7627 VRS-CY1JD132F J 1.3K 1/10W Metal Oxide AA
R7628 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7629 VRS-CY1JD132F J 1.3K 1/10W Metal Oxide AA
R7630 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7631 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7632 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7633 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7634 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
MISCELLANEOUS PARTS
P7601 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7602 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7603 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7604 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
