Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
RUNTKA080WJZZ (LC-37G4U/G4D)
INVERTER-1 Unit(Continued)
RUNTKA081WJZZ (LC-37G4U/G4D)
INVERTER-2 Unit
R7519 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7521 VRS-CY1JD753F J 75K 1/10W Metal Oxide AA
R7523 VRS-CY1JD104F J 100K1/10W Metal Oxide AA
R7525 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7526 VRS-CY1JD101J J 100 1/10W Metal Oxide AA
R7527 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7528 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7529 VRS-CY1JD101J J 100 1/10W Metal Oxide AA
R7530 VRS-CY1JD104F J 100K1/10W Metal Oxide AA
R7533 VRS-CY1JD102F J 1K 1/10W Metal Oxide AA
R7534 VRS-CY1JD101F J 100 1/10W Metal Oxide AA
R7536 VRS-CY1JD112F J 1.1K 1/10W Metal Oxide AA
R7537 VRS-CY1JD112F J 1.1K 1/10W Metal Oxide AA
R7539 VRS-CY1JD513F J 51K 1/10W Metal Oxide AA
R7540 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7543 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7545 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7548 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7549 VRS-TW2ED000J J 0 1/4W Metal Oxide AB
R7555 VRS-CY1JD513F J 51K 1/10W Metal Oxide AA
R7556 VRS-CY1JD753F J 75K 1/10W Metal Oxide AA
R7557 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7559 VRS-TP2BD000J J 0 1/4W AA
R7560 VRS-TP2BD000J J 0 1/4W AA
R7561 VRS-TP2BD000J J 0 1/4W AA
R7562 VRS-TP2BD000J J 0 1/4W AA
R7563 VRS-TP2BD000J J 0 1/4W AA
R7564 VRS-TP2BD000J J 0 1/4W AA
R7565 VRS-TP2BD000J J 0 1/4W AA
R7566 VRS-TP2BD000J J 0 1/4W AA
R7567 VRS-TP2BD000J J 0 1/4W AA
R7568 VRS-TP2BD000J J 0 1/4W AA
FUSES AND FUSE HOLDERS
åF7501 QFS-A1153SNEZ J Fuse, TLC N4 10A/250V AF
FH7501 QFSHA1012SNEZ J Fuse Holder, H-0017-2 AD
FH7502 QFSHA1012SNEZ J Fuse Holder, H-0017-2 AD
MISCELLANEOUS PARTS
P7501 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7502 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
P7503 QCNCM1821SNEZ J Plug, 3Pin, 1717823-1 AD
P7504 QCNCM1821SNEZ J Plug, 3Pin, 1717823-2 AD
P7505 QCNCM1828SNEZ J Plug, 2Pin, 1717823-3 AC
P7506 QCNCM1819SNEZ J Plug, 12Pin, 1717823-4 AD
P7507 QCNCM1826SNEZ J Plug, 12Pin, 1717823-5 AE
P7508 QCNCM1821SNEZ J Plug, 2Pin, 1717823-6 AD
LUG7501 QTAND1019SNEZ J GND Lug, 1717823-7 AD
LUG7502 QTAND1019SNEZ J GND Lug, 1717823-8 AD
LUG7503 QTAND1019SNEZ J GND Lug, 1717823-9 AD
LUG7504 QTAND1019SNEZ J GND Lug, 1717823-10 AD
INTEGRATED CIRCUIT
IC7402 VHIBD9766FV/-1 J BD9766FV AR
TRANSISTORS
Q7401 VSRSS075P03-1 J RSS075P03 AH
Q7402 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7403 VSRSS100N03-1 J RSS100N03 AG
Q7404 VSRSS075P03-1 J RSS075P03 AH
Q7406 VSRSS100N03-1 J RSS100N03 AG
Q7407 VSRSS075P03-1 J RSS075P03 AH
Q7409 VSRSS100N03-1 J RSS100N03 AG
Q7410 VSRSS075P03-1 J RSS075P03 AH
Q7411 VSRSS100N03-1 J RSS100N03 AG
DIODES
D7401 VHDDAN217U/-1 J DAN217U AC
D7402 VHDDAN217U/-1 J DAN217U AC
D7403 VHDRB070M30-1 J RB070M-30 AD
D7404 VHDRB070M30-1 J RB070M-30 AD
D7406 VHDDAN217U/-1 J DAN217U AC
D7407 VHDDAN217U/-1 J DAN217U AC
D7408 VHDRB070M30-1 J RB070M-30 AD
D7409 VHDRB070M30-1 J RB070M-30 AD
D7410 VHDDAN217U/-1 J DAN217U AC
D7411 VHDDAN217U/-1 J DAN217U AC
D7412 VHDRB070M30-1 J RB070M-30 AD
D7413 VHDRB070M30-1 J RB070M-30 AD
D7414 VHEHZU5.1B/-1 J Zener Diode
HZU5.1B(RD5.1SB)
D7415 VHD1SS355//-1 J 1SS355 AB
D7417 VHEHZU5.1B/-1 J Zener Diode
HZU5.1B(RD5.1SB)
D7418 VHDDAN217U/-1 J DAN217U AC
D7419 VHDDAN217U/-1 J DAN217U AC
D7420 VHDRB070M30-1 J RB070M-30 AD
D7421 VHDRB070M30-1 J RB070M-30 AD
TRANSFORMERS
T7401 RTRNZA046WJZZ J 1048HG-1001 AU
T7402 RTRNZA046WJZZ J 1048HG-1001 AU
T7403 RTRNZA046WJZZ J 1048HG-1001 AU
T7404 RTRNZA046WJZZ J 1048HG-1001 AU
CAPACITORS
C7401 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7402 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7403 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7404 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7405 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7406 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7408 RC-E1E337KZES J 330 25V Electrolytic AE
C7409 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7410 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7411 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7412 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7413 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7414 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7415 RCE1E337KZEBC J 330 25V Electrolytic AE
C7416 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7417 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7418 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7419 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7420 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7421 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7422 VCKYCY1CB473K J 0.047 16V Ceramic AA
C7423 RC-E1E337KZES J 330 25V Electrolytic AE
C7424 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7426 VCKYCY1HB472K J 4700p 50V Ceramic AA
C7427 VCKYCY1HB222K J 2200p 50V Ceramic AA
C7428 VCKYCY1HB472K J 4700p 50V Ceramic AA
C7429 VCKYCY1HB222K J 2200p 50V Ceramic AA
