Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
RUNTKA072WJZZ (LC-32G4U/G4D)
INVERTER-2 GND Unit(Continued)
RUNTKA080WJZZ (LC-37G4U/G4D)
INVERTER-1 Unit
THERMISTOR
TH7653 VHH18XH103J03 J NCP18XH103J03RB AC
MISCELLANEOUS PARTS
CN7651 QCNCM1823SNEZ J Plug, 5Pin, 05R-FJ AC
CN7652 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7653 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7654 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7655 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
LUG7651 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7652 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7653 QTAND1019SNEZ J GND Lug, SD01138-21 AD
JP7651 VRS-TP2BD000J J GND Lug, 0, 1/4W AA
JP7652 VRS-TP2BD000J J GND Lug, 0, 1/4W AA
JP7653 VRS-TP2BD000J J GND Lug, 0, 1/4W AA
INTEGRATED CIRCUITS
IC7501 VHIBD9766FV/-1 J BD9766FV AR
IC7502 VHIBA00ASFP/-1 J BA00ASFP AK
TRANSISTORS
Q7501 VSRSS075P03-1 J RSS075P03 AH
Q7502 VSRSS075P03-1 J RSS075P03 AH
Q7503 VSRSS075P03-1 J RSS075P03 AH
Q7504 VSRSS075P03-1 J RSS075P03 AH
Q7505 VSRSS075P03-1 J RSS075P03 AH
Q7506 VSRSS100N03-1 J RSS100N03 AG
Q7507 VSRSS100N03-1 J RSS100N03 AG
Q7508 VSRSS100N03-1 J RSS100N03 AG
Q7509 VSRSS100N03-1 J RSS100N03 AG
Q7510 VSRSS100N03-1 J RSS100N03 AG
Q7511 VSUM6K1N///-1 J UM6K1N, MOS FET AD
DIODES
D7501 VHDDAN217U/-1 J DAN217U AC
D7502 VHDDAN217U/-1 J DAN217U AC
D7503 VHDDAN217U/-1 J DAN217U AC
D7504 VHDDAN217U/-1 J DAN217U AC
D7505 VHDDAN217U/-1 J DAN217U AC
D7506 VHDDAN217U/-1 J DAN217U AC
D7507 VHDDAN217U/-1 J DAN217U AC
D7508 VHDDAN217U/-1 J DAN217U AC
D7509 VHDDAN217U/-1 J DAN217U AC
D7510 VHDDAN217U/-1 J DAN217U AC
D7511 VHDRB070M30-1 J RB070M-30 AD
D7512 VHDRB070M30-1 J RB070M-30 AD
D7513 VHDRB070M30-1 J RB070M-30 AD
D7514 VHDRB070M30-1 J RB070M-30 AD
D7515 VHDRB070M30-1 J RB070M-30 AD
D7516 VHDRB070M30-1 J RB070M-30 AD
D7517 VHDRB070M30-1 J RB070M-30 AD
D7518 VHDRB070M30-1 J RB070M-30 AD
D7519 VHDRB070M30-1 J RB070M-30 AD
D7520 VHDRB070M30-1 J RB070M-30 AD
D7521 VHEHZU5.1B/-1 J Zener Diode, HZU5.1B(RD5.1SB)
D7522 VHEHZU5.1B/-1 J Zener Diode, HZU5.1B(RD5.1SB)
D7523 VHD1SS355//-1 J 1SS355 AB
TRANSFORMERS
T7501 RTRNZA046WJZZ J 1048HG-1001 AU
T7502 RTRNZA046WJZZ J 1048HG-1001 AU
T7503 RTRNZA046WJZZ J 1048HG-1001 AU
T7504 RTRNZA046WJZZ J 1048HG-1001 AU
T7505 RTRNZA046WJZZ J 1048HG-1001 AU
CAPACITORS
C7503 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7504 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7505 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7506 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7507 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7508 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7509 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7510 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7511 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7512 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7513 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7514 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7515 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7516 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7517 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7518 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7519 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7520 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7521 RC-ECC3H120JM J 12p 5kV Ceramic AF
C7522 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7523 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7524 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7525 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7526 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7527 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7528 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7529 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7530 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7531 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7532 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7533 VCKYCY1CB473K J 0.047 16V Ceramic AA
C7534 RC-E1E337KZES J 330 25V Electrolytic AE
C7535 RC-E1E337KZES J 330 25V Electrolytic AE
C7536 VCKYCY1CB473K J 0.047 16V Ceramic AA
C7537 RC-E1E337KZES J 330 25V Electrolytic AE
C7538 RC-E1E337KZES J 330 25V Electrolytic AE
C7539 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7540 VCKYTV1AB225K J 2.2 10V Ceramic AC
C7541 VCKYTV1AB225K J 2.2 10V Ceramic AC
C7542 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7543 VCKYCY1CB104K J 0.1 16V Ceramic AB
C7544 VCCCCY1HH331J J 330p 50V Ceramic AA
C7546 VCKYCY1HB472K J 4700p 50V Ceramic AA
C7547 VCKYCY1HB222K J 2200p 50V Ceramic AA
C7549 VCKYCY1HB472K J 4700p 50V Ceramic AA
C7550 VCKYCY1HB222K J 2200p 50V Ceramic AA
C7555 RC-E1E337KZES J 330 25V Electrolytic AE
C7566 VCKYCY1HB103K J 0.01 50V Ceramic AA
RESISTORS
R7501 VRS-CY1JD333F J 33K 1/10W Metal Oxide AA
R7502 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7503 VRS-CY1JD333F J 33K 1/10W Metal Oxide AA
R7504 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7505 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7506 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7507 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7508 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7509 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7510 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7511 VRS-CY1JD102F J 1K 1/10W Metal Oxide AA
R7512 VRS-CY1JD363F J 36K 1/10W Metal Oxide AA
R7513 VRS-CY1JD473F J 47K 1/10W Metal Oxide AA
R7514 VRS-CY1JD222F J 2.2K 1/10W Metal Oxide AA
R7515 VRS-CY1JD682F J 6.8K 1/10W Metal Oxide AA
R7516 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7517 VRS-CY1JD101F J 100 1/10W Metal Oxide AA
R7518 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
