Sharp LC-32G4U User Manual

119
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
RUNTKA071WJZZ (LC-32G4U/G4D)
INVERTER-1 GND Unit
TRANSISTORS
Q7601 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7602 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7603 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7604 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7605 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7606 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7607 VSUM6K1N///-1 J UM6K1N, MOSFET AD
DIODES
D7601 VHD1SS355//-1 J 1SS355 AB
D7602 VHD1SS355//-1 J 1SS355 AB
D7603 VHD1SS355//-1 J 1SS355 AB
D7604 VHD1SS355//-1 J 1SS355 AB
D7605 VHD1SS362//-1 J 1SS362 AC
D7606 VHD1SS355//-1 J 1SS355 AB
D7607 VHD1SS355//-1 J 1SS355 AB
D7608 VHD1SS355//-1 J 1SS355 AB
CAPACITORS
C7601 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7602 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7603 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7604 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7606 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7607 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7608 VCKYCY1CB224K J 0.22 16V Ceramic AB
RESISTORS
R7601 VRS-CY1JD155J J 1.5M 1/10W AA
R7602 VRS-CY1JD104J J 100K1/10W AA
R7603 VRS-CY1JD155J J 1.5M 1/10W AA
R7604 VRS-CY1JD104J J 100K1/10W AA
R7605 VRS-CY1JD155J J 1.5M 1/10W AA
R7606 VRS-CY1JD104J J 100K1/10W AA
R7607 VRS-CY1JD155J J 1.5M 1/10W AA
R7608 VRS-CY1JD104J J 100K1/10W AA
R7609 VRS-CY1JD911F J 910 1/10W AA
R7610 VRS-CY1JD242F J 2.4K 1/10W AA
R7611 VRS-CY1JD155J J 1.5M 1/10W AA
R7612 VRS-CY1JD104J J 100K1/10W AA
R7613 VRS-CY1JD155J J 1.5M 1/10W AA
R7614 VRS-CY1JD104J J 100K1/10W AA
R7615 VRS-CY1JD155J J 1.5M 1/10W AA
R7616 VRS-CY1JD104J J 100K1/10W AA
R7625 VRS-CY1JD000J J 0 1/10W AA
R7626 VRS-CY1JD202J J 2K 1/10W AA
R7627 VRS-CY1JD202J J 2K 1/10W AA
R7628 VRS-CY1JD202J J 2K 1/10W AA
R7629 VRS-CY1JD202J J 2K 1/10W AA
R7630 VRS-CY1JD202J J 2K 1/10W AA
R7631 VRS-CY1JD202J J 2K 1/10W AA
R7632 VRS-CY1JD202J J 2K 1/10W AA
R7633 VRS-CY1JD202J J 2K 1/10W AA
R7634 VRS-CY1JD103F J 10K 1/10W AA
R7636 VRS-CY1JD202J J 2K 1/10W AA
R7637 VRS-CY1JD202J J 2K 1/10W AA
R7638 VRS-CY1JD202J J 2K 1/10W AA
R7639 VRS-CY1JD202J J 2K 1/10W AA
R7640 VRS-CY1JD202J J 2K 1/10W AA
R7641 VRS-CY1JD202J J 2K 1/10W AA
MISCELLANEOUS PARTS
CN7601 QCNCM1796SNEZ J Plug, 8Pin, S08B-PASK-2 AD
CN7602 QCNCM1822SNEZ J Plug, 5Pin, 05PL-FJ AD
CN7603 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7604 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7605 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7606 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
LUG7601 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7602 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7603 QTAND1019SNEZ J GND Lug, SD01138-21 AD
JP7601 VRS-TP2BD000J J 1/4W 0 AA
JP7602 VRS-TP2BD000J J 1/4W 0 AA
JP7603 VRS-TP2BD000J J 1/4W 0 AA
RUNTKA072WJZZ (LC-32G4U/G4D)
INVERTER-2 GND Unit
TRANSISTORS
Q7651 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7652 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7653 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7654 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7655 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7656 VSUM6K1N///-1 J UM6K1N, MOSFET AD
Q7657 VSUM6K1N///-1 J UM6K1N, MOSFET AD
DIODES
D7651 VHD1SS355//-1 J 1SS355 AB
D7652 VHD1SS355//-1 J 1SS355 AB
D7653 VHD1SS355//-1 J 1SS355 AB
D7654 VHD1SS355//-1 J 1SS355 AB
D7655 VHD1SS362//-1 J 1SS362 AC
D7656 VHD1SS355//-1 J 1SS355 AB
D7657 VHD1SS355//-1 J 1SS355 AB
D7658 VHD1SS355//-1 J 1SS355 AB
CAPACITORS
C7651 VCKYCY1CB224K J 0.22uF 16V Ceramic AB
C7652 VCKYCY1CB224K J 0.22uF 16V Ceramic AB
C7653 VCKYCY1CB224K J 0.22uF 16V Ceramic AB
C7654 VCKYCY1CB224K J 0.22uF 16V Ceramic AB
C7656 VCKYCY1CB224K J 0.22uF 16V Ceramic AB
C7657 VCKYCY1CB224K J 0.22uF 16V Ceramic AB
C7658 VCKYCY1CB224K J 0.22uF 16V Ceramic AB
RESISTORS
R7651 VRS-CY1JD155J J 1.5M 1/10W Metal Oxide AA
R7652 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7653 VRS-CY1JD155J J 1.5M 1/10W Metal Oxide AA
R7654 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7655 VRS-CY1JD155J J 1.5M 1/10W Metal Oxide AA
R7656 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7657 VRS-CY1JD155J J 1.5M 1/10W Metal Oxide AA
R7658 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7659 VRS-CY1JD911F J 910 1/10W Metal Oxide AA
R7660 VRS-CY1JD242F J 2.4K 1/10W Metal Oxide AA
R7661 VRS-CY1JD155J J 1.5M 1/10W Metal Oxide AA
R7662 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7663 VRS-CY1JD155J J 1.5M 1/10W Metal Oxide AA
R7664 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7665 VRS-CY1JD155J J 1.5M 1/10W Metal Oxide AA
R7666 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7674 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7675 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7676 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7677 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7678 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7679 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7680 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7681 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7682 VRS-CY1JD103F J 10K 1/10W Metal Oxide AA
R7684 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7685 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7686 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7687 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7688 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7689 VRS-CY1JD202J J 2K 1/10W Metal Oxide AA
R7691 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
