Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
RUNTKA069WJZZ (LC-32G4U/G4D)
INVERTER-1 Unit (Continued)
R7515 VRS-CY1JD513F J 51K 1/10W Metal Oxide AA
R7516 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7517 VRS-CY1JD221J J 220 1/10W Metal Oxide AA
R7518 VRS-CY1JD221J J 220 1/10W Metal Oxide AA
R7519 VRS-CY1JD103J J 10K 1/10W Metal Oxide AA
R7520 VRS-CY1JD103J J 10K 1/10W Metal Oxide AA
R7521 VRS-CY1JD513F J 51K 1/10W Metal Oxide AA
R7522 VRS-CY1JD683F J 68K 1/10W Metal Oxide AA
R7523 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7526 VRS-TP2BD000J J 0 1/4W AA
R7528 VRS-TP2BD000J J 0 1/4W AA
R7529 VRS-TP2BD220J J 22 1/4W AA
R7530 VRS-TP2BD220J J 22 1/4W AA
R7531 VRS-TP2BD220J J 22 1/4W AA
R7532 VRS-TP2BD220J J 22 1/4W AA
R7533 VRS-CY1JD103J J 10K 1/10W Metal Oxide AA
R7534 VRS-TP2BD220J J 22 1/4W AA
R7535 VRS-TP2BD220J J 22 1/4W AA
R7536 VRS-TP2BD220J J 22 1/4W AA
R7537 VRS-TP2BD220J J 22 1/4W AA
R7538 VRS-CY1JD513J J 51K 1/10W Metal Oxide AA
R7541 VRS-CY1JD473F J 47K 1/10W Metal Oxide AA
R7542 VRS-CY1JD513J J 51K 1/10W Metal Oxide AA
R7545 VRS-CY1JD753F J 75K 1/10W Metal Oxide AA
FUSE
åF7501 QFS-A1152SNEZ J Fuse, BL6.3A/250V AD
MISCELLANEOUS PARTS
CN7501 QCNCM1818SNEZ J Plug, 3Pin, B3P-VH AC
CN7502 QCNCM1819SNEZ J Plug, 12Pin, B12B-PASK-1 AD
CN7503 QCNCM1822SNEZ J Plug, 5Pin, 05PL-FJ AD
CN7504 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7505 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7506 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7507 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
LUG7501 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7502 QTAND1019SNEZ J GND Lug, SD01138-21 AD
JP7502 QJUM-1003SNEZ J Jumper, MJ-0.1-T
TRANSISTORS
Q7401 VSRSS050P03-1 J RSS050P03 AG
Q7402 VSRSS065N03-1 J RSS065N03
Q7403 VSRSS050P03-1 J RSS050P03 AG
Q7404 VSRSS065N03-1 J RSS065N03
Q7405 VSRSS050P03-1 J RSS050P03 AG
Q7406 VSRSS065N03-1 J RSS065N03
Q7407 VSRSS050P03-1 J RSS050P03 AG
Q7408 VSRSS065N03-1 J RSS065N03
DIODES
D7401 VHD1SS362//-1 J 1SS362 AC
D7402 VHD1SS362//-1 J 1SS362 AC
D7403 VHD1SS362//-1 J 1SS362 AC
D7404 VHD1SS362//-1 J 1SS362 AC
D7405 VHD1SS362//-1 J 1SS362 AC
D7406 VHD1SS362//-1 J 1SS362 AC
D7407 VHD1SS362//-1 J 1SS362 AC
D7408 VHD1SS362//-1 J 1SS362 AC
ZD7401 VHEHZU8.2B2-1 J HZU8.2B2, Zener Diode AC
TRANSFORMERS
T7401 RTRNZ1257SNEZ J RT990TN-1218 AM
T7402 RTRNZ1256SNEZ J T990TN-1217 AM
T7403 RTRNZ1257SNEZ J RT990TN-1218 AM
T7404 RTRNZ1256SNEZ J T990TN-1217 AM
T7405 RTRNZ1257SNEZ J RT990TN-1218 AM
T7406 RTRNZ1256SNEZ J T990TN-1217 AM
T7407 RTRNZ1257SNEZ J RT990TN-1218 AM
T7408 RTRNZ1256SNEZ J T990TN-1217 AM
CAPACITORS
C7403 VCKYCY1EB473K J 0.047 25V Ceramic AA
C7404 RC-E1E337KZES J 330 25V Electrolytic AE
C7405 RC-E1E337KZES J 330 25V Electrolytic AE
C7406 RC-E1E337KZES J 330 25V Electrolytic AE
C7407 RC-E1E337KZES J 330 25V Electrolytic AE
C7408 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7409 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7410 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7411 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7412 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7413 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7414 VCKYTQ1EB475K J 4.7uF 25V Ceramic AD
C7415 VCKYTQ1EB475K J 4.7uF 25V Ceramic AD
C7416 RC-CF180J3KV1 J 18pF 3kV Ceramic AE
C7417 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7418 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7419 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7420 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7421 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7422 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7423 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7424 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7425 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7426 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7427 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7428 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7429 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7430 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7431 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7432 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7433 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7434 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7435 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7436 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7437 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7438 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7439 VCKYTQ2AB473K J 0.047 100V Ceramic AC
RESISTORS
R7402 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7404 VRS-TP2BD000J J 0 1/4W AA
R7406 VRS-TP2BD000J J 0 1/4W AA
R7407 VRS-CY1JD103J J 10K 1/10W Metal Oxide AA
R7408 VRS-TP2BD220J J 22 1/4W AA
R7409 VRS-TP2BD220J J 22 1/4W AA
R7410 VRS-TP2BD220J J 22 1/4W AA
R7411 VRS-TP2BD220J J 22 1/4W AA
R7412 VRS-TP2BD220J J 22 1/4W AA
R7413 VRS-TP2BD220J J 22 1/4W AA
R7414 VRS-TP2BD220J J 22 1/4W AA
R7415 VRS-TP2BD220J J 22 1/4W AA
FUSE
åF7401 QFS-A1152SNEZ J Fuse, BL6.3A/250V AD
MISCELLANEOUS PARTS
CN7401 QCNCM1817SNEZ J Plug, 2Pin, B2P-VH AC
CN7402 QCNCM1823SNEZ J Plug, 5Pin, 05R-FJ AC
CN7403 QCNCM1821SNEZ J Plug, 2Pin,1717823-1 AD
CN7404 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7405 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
CN7406 QCNCM1821SNEZ J Plug, 2Pin, 1717823-1 AD
LUG7401 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7402 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7403 QTAND1019SNEZ J GND Lug, SD01138-21 AD
LUG7404 QTAND1019SNEZ J GND Lug, SD01138-21 AD
JP7401 QJUM-1003SNEZ J Jumper, MJ-0.1-T
RUNTKA070WJZZ (LC-32G4U/G4D)
INVERTER-2 Unit
