Sharp LC-32G4U User Manual

117
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
RUNTKA069WJZZ (LC-32G4U/G4D)
INVERTER-1 Unit
BEA2705 95CL5051AQ002 J BL02RN2-R62 T2, Ferrite Beads AD
BEA2751 95CL5051AQ002 J BL02RN2-R62 T2, Ferrite Beads AD
BEA3751 95CL5051AQ002 J BL02RN2-R62 T2, Ferrite Beads AD
BEA4751 95CL5051AQ002 J BL02RN2-R62 T2, Ferrite Beads AD
NTC2701 95CD8118AR001 J NTC Thermistor AP
NTPAD3R9LD6AZ
NTC2702 95CD8118AR001 J NTC Thermistor AP
NTPAD3R9LD6AZ
NTC2703 95CD7059AQ4R0 J NTC Thermistor AK
NTH7D4R0LHT62A
NTC2704 95CD7059AQ4R0 J NTC Thermistor AK
NTH7D4R0LHT62A
PTC2701 95CD8002AQ110 J Posistor AM
PTH9M04BC222TS2F333
å CN2701 95CK2108SL001 J Plug, NC-133L-D-1 AL
CN2702 95CK2120BS003 J Connector AN
B5P(10-2,3,5,7,9)S-VH
CN4701 95CK2025BQ004 J Connector, B4PS-VH AL
CN3701 95CK2144BS007 J Connector AM
Connector S07B-PASK-2
FG1 95CK2052PQ005 J Connector, EARTH AE
TERMINAL(M3) TP00370-41
FG2 95CK2052PQ005 J Connector, EARTH AE
TERMINAL(M3) TP00370-41
FG3 95CK2052PQ005 J Connector, EARTH AE
TERMINAL(M3) TP00370-41
FG4 95CK2052PQ005 J Connector, EARTH AE
TERMINAL(M3) TP00370-41
å PC2701 95CH7148AS001 J PC123Y82FZ AH
å PC2702 95CH7148AS001 J PC123Y82FZ AH
å PC2703 95CH7148AS001 J PC123Y82FZ AH
å PC3701 95CH7148AS001 J PC123Y82FZ AH
PC4701 95CH7148AS001 J PC123Y82FZ AH
INTEGRATED CIRCUITS
IC7501 VHIBD9766FV/-1 J BD9766FV AR
IC7502 VHINJM78L08UA J NJM78L08UA(TA7808F) AE
TRANSISTORS
Q7501 VSRSS050P03-1 J RSS050P03 AG
Q7502 VSRSS065N03-1 J RSS065N03
Q7503 VSRSS050P03-1 J RSS050P0 AG
Q7504 VSRSS065N03-1 J RSS065N03
Q7505 VSRSS050P03-1 J RSS050P03 AG
Q7506 VSRSS065N03-1 J RSS065N03
Q7507 VSRSS050P03-1 J RSS050P03 AG
Q7508 VSRSS065N03-1 J RSS065N03
Q7513 VSUM6K1N///-1 J UM6K1N, MOSFET AD
DIODES
D7501 VHD1SS355//-1 J 1SS355 AB
D7502 VHD1SS362//-1 J 1SS362 AC
D7503 VHD1SS362//-1 J 1SS362 AC
D7504 VHD1SS362//-1 J 1SS362 AC
D7505 VHD1SS362//-1 J 1SS362 AC
D7506 VHD1SS362//-1 J 1SS362 AC
D7507 VHD1SS362//-1 J 1SS362 AC
D7508 VHD1SS362//-1 J 1SS362 AC
D7509 VHD1SS362//-1 J 1SS362 AC
ZD7501 VHEHZU8.2B2-1 J Zener Diode, HZU8.2B2 AC
TRANSFORMERS
T7501 RTRNZ1257SNEZ J RT990TN-1218 AM
T7502 RTRNZ1256SNEZ J T990TN-1217 AM
T7503 RTRNZ1257SNEZ J RT990TN-1218 AM
T7504 RTRNZ1256SNEZ J T990TN-1217 AM
T7505 RTRNZ1257SNEZ J RT990TN-1218 AM
T7506 RTRNZ1256SNEZ J T990TN-1217 AM
T7507 RTRNZ1257SNEZ J RT990TN-1218 AM
T7508 RTRNZ1256SNEZ J T990TN-1217 AM
CAPACITORS
C7502 VCCCCY1HH331J J 330p 50V Ceramic AA
C7503 VCKYCY1HB222K J 2200p 50V Ceramic AA
C7504 VCKYCY1HB332K J 3300p 50V Ceramic AA
C7505 VCKYCY1HB222K J 2200p 50V Ceramic AA
C7506 VCKYCY1HB332K J 3300p 50V Ceramic AA
C7507 VCKYCY1EB104K J 0.1 25V Ceramic AA
C7508 VCKYCY1CB224K J 0.22 16V Ceramic AB
C7509 VCKYTV1AB225K J 2.2 10V Ceramic AC
C7510 VCKYTV1AB225K J 2.2 10V Ceramic AC
C7511 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7512 VCKYCY1EB104K J 0.1 25V Ceramic AA
C7513 VCKYCY1EB104K J 0.1 25V Ceramic AA
C7516 VCKYCY1EB473K J 0.047 25V Ceramic AA
C7517 RC-E1E337KZES J 330 25V Electrolytic AE
C7518 RC-E1E337KZES J 330 25V Electrolytic AE
C7519 RC-E1E337KZES J 330 25V Electrolytic AE
C7520 RC-E1E337KZES J 330 25V Electrolytic AE
C7521 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7522 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7523 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7524 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7525 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7526 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7527 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7528 VCKYTQ1EB475K J 4.7 25V Ceramic AD
C7529 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7530 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7531 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7532 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7533 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7534 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7535 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7536 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7537 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7538 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7539 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7540 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7541 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7542 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7543 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7544 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7545 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7546 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7547 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7548 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7549 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7550 RC-CF180J3KV1 J 18p 3kV Ceramic AE
C7551 VCKYCY1EB223K J 0.022 25V Ceramic AA
C7552 VCKYTQ2AB473K J 0.047 100V Ceramic AC
C7553 VCKYCY1HB103K J 0.01 50V Ceramic AA
RESISTORS
R7501 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7504 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7505 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7506 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7507 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7508 VRS-CY1JD363F J 36K 1/10W Metal Oxide AA
R7509 VRS-CY1JD753F J 75K 1/10W Metal Oxide AA
R7510 VRS-CY1JD102J J 1K 1/10W Metal Oxide AA
R7511 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7512 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
R7513 VRS-CY1JD104J J 100K1/10W Metal Oxide AA
R7514 VRS-CY1JD000J J 0 1/10W Metal Oxide AA
RDENCA058WJZZ (LC-32/37G4U)
RDENCA059WJZZ (LC-32/37G4D)
POWER SUPPLY Unit(Continued)
