Pin No Terminal Name I/O Description
Pin No Terminal Name I/O Description
K7 GND GND
K8 GND GND
K9 GND GND
K10 GND GND
K11 VCC2.5 VCC 2.5 V input
K12 RB2NA RB2NA (differential output)
K13 RB1PA RB1PA (differential output)
K14 RB1NA RB1NA (differential output)
K15 NC NC
K16 RB0PA RB0PA (differential output)
L1 VCC2.5 VCC 2.5 V input
L2 LCKPA LCKPA (differential output)
L3 LCKNA LCKNA (differential output)
L4 LG0PA LG0PA (differential output)
L5 LG0NA LG0NA (differential output)
L6 GND GND
L7 VCC2.5 VCC 2.5 V input
L8 VCC2.5 VCC 2.5 V input
L9 VCC2.5 VCC 2.5 V input
L10 VCC2.5 VCC 2.5 V input
L11 GND GND
L12 RB2PA RB2PA (differential output)
L13 RG2NA RG2NA (differential output)
L14 RG3PA RG3PA (differential output)
L15 RG3NA RG3NA (differential output)
L16 VCC2.5 VCC 2.5 V input
M1 LG1PA LG1PA (differential output)
M2 LG1NA LG1NA (differential output)
M3 LG2PA LG2PA (differential output)
M4 LG2NA LG2NA (differential output)
M5 VCC1.2 VCC 1.2 V input
M6 NC NC
M7 LB3PA LB3PA (differential output)
M8 VCC2.5 VCC 2.5 V input
M9 VCC2.5 VCC 2.5 V input
M10 RR0NA RR0NA (differential output)
M11 DIN CONFIG DIN input
M12 VCC1.2 VCC 1.2 V input
M13 RG2PA RG2PA (differential output)
M14 RG0NA RG0NA (differential output)
M15 RG1PA RG1PA (differential output)
M16 RG1NA RG1NA (differential output)
N1 LG3PA LG3PA (differential output)
N2 LG3NA LG3NA (differential output)
N3 LB0PA LB0PA (differential output)
N4 VCC1.2 VCC 1.2 V input
N5 NC NC
N6 NC NC
N7 LB3NA LB3NA (differential output)
N8 NC NC
N9 CPLD_RST CONFIG_RST input
N10 RR0PA RR0PA (differential output)
N11 NC NC
N12 NC NC
N13 VCC1.2 VCC 1.2 V input
N14 RG0PA RG0PA (differential output)
N15 RCKPA RCKPA (differential output)
N16 RCKNA RCKNA (differential output)
P1 OOEM_INV OEM_INV output
P2 LB0NA LB0NA (differential output)
P3 M0 Mode setting terminal
P4 M2 Mode setting terminal
P5 LB1PA LB1PA (differential output)
P6 LB2PA LB2PA (differential output)
P7 NC NC
P8 NC NC
P9 CPLD_D1 CONFIG_D1 input
P10 NC NC
P11 RR1NA RR1NA (differential output)
P12 RR2NA RR2NA (differential output)
P13 NC NC
P14 RR3PA RR3PA (differential output)
P15 RR3NA RR3NA (differential output)
P16 NC NC
R1 OOEM OEM output
R2 GND GND
R3 NC NC
R4 NC NC
R5 LB1NA LB1NA (differential output)
R6 LB2NA LB2NA (differential output)
R7 NC NC
R8 GND GND
R9 NC NC
R10 NC NC
R11 RR1PA RR1PA (differential output)
R12 RR2PA RR2PA (differential output)
R13 NC NC
R14 CPLD_DONE CONFIG_DONE output
R15 GND GND
R16 NC NC
T1 GND GND
T2 M1 Mode setting terminal
T3 NC NC
T4 NC NC
T5 NC NC
T6 VCC2.5 VCC 2.5 V input
T7 NC NC
T8 NC NC
T9 NC NC
T10 NC NC
