Sharp LC-32G4U User Manual

35
LC-32G4U/G4D
LC-37G4U/G4D



Pin No Terminal Name I/O Description 
Pin No Terminal Name I/O Description
D3 GE1 GE1 input D4 VCC1.2 VCC 1.2 V input D5 GE5 GE5 input D6 GE4 GE4 input D7 GE3 GE3 input D8 GE2 GE2 input D9 MP_CS Three-wire serial bus CS input D10 GO4 GO4 input D11 GO3 GO3 input D12 BO7 BO7 input D13 VCC1.2 VCC 1.2 V input D14 GO0 GO0 input D15 RO2 RO2 input D16 RO1 RO1 input E1 PMUTE PMUTE output E2 RE7 RE7 input E3 RE6 RE6 input E4 RE5 RE5 input E5 VCC1.2 VCC 1.2 V input E6 GE7 GE7 input E7 GE6 GE6 input E8 VCC3.3 VCC 3.3 V input E9 VCC3.3 VCC 3.3 V input E10 GO7 GO7 input E11 GO6 GO6 input E12 VCC1.2 VCC 1.2 V input E13 RO7 RO7 input E14 RO6 RO6 input E15 RO5 RO5 input E16 RO4 RO4 input F1 VCC2.5 VCC 2.5 V input F2 INT_H INT_H output F3 INT_DE INT_DE output F4 INT_CKE INT_CKE output F5 INT_CKO INT_CKO output F6 GND GND F7 VCC3.3 VCC 3.3 V input F8 VCC3.3 VCC 3.3 V input F9 VCC3.3 VCC 3.3 V input F10 VCC3.3 VCC 3.3 V input F11 GND GND F12 GO5 GO5 input F13 NC NC F14 NC NC F15 OGSP1 Panel control signal output F16 VCC2.5 VCC2.5V input G1 LSPOI1 Panel control signal output G2 LSPIO1 Panel control signal output G3 OLS Panel control signal output G4 INT_V INT_V output
G5 OLBR Panel control signal output G6 VCC3.3 VCC 3.3 V input G7 GND GND G8 GND GND G9 GND GND G10 GND GND G11 VCC3.3 VCC 3.3 V input G12 NC NC G13 NC NC G14 NC NC G15 OGCK Panel control signal output G16 OGSP2 Panel control signal output H1 RSPOI1 Panel control signal output H2 GND GND H3 RSPIO1 Panel control signal output H4 OREV Panel control signal output H5 VCC3.3 VCC 3.3 V input H6 VCC3.3 VCC 3.3 V input H7 GND GND H8 GND GND H9 GND GND H10 GND GND H11 VCC3.3 VCC 3.3 V input H12 VCC3.3 VCC 3.3 V input H13 NC NC H14 OGLBR2 Panel control signal output H15 OPOW Panel control signal output H16 OGLBR1 Panel control signal output J1 LR0PA LR0PA (differential output) J2 LR0NA LR0NA (differential output) J3 LR1PA LR1PA (differential output) J4 LR1NA LR1NA (differential output) J5 VCC2.5 VCC 2.5 V input J6 VCC2.5 VCC 2.5 V input J7 GND GND J8 GND GND J9 GND GND J10 GND GND J11 VCC2.5 VCC 2.5 V input J12 VCC2.5 VCC 2.5 V input J13 RB3PA RB3PA (differential output) J14 RB3NA RB3NA (differential output) J15 GND GND J16 RB0NA RB0NA (differential output) K1 NC NC K2 LR2PA LR2PA (differential output) K3 LR2NA LR2NA (differential output) K4 LR3PA LR3PA (differential output) K5 LR3NA LR3NA (differential output) K6 VCC2.5 VCC 2.5 V input

