201 AVCC 3.3 V
202 X_RES Impedance matching control input
203 PVCC 3.3 V
204 PGND GND
205 NC Not used
206 NC Not used
207 GND GND
208 DVCC 2.5 V
Pin No Terminal Name I/O Description
A1 GND GND
A2 TDI Pull-up
A3 DDC_RST Reset input
A4 MP_DA Three-wire serial bus data input
A5 INV_OSC Inverter oscillating frequency output
A6 VCC2.5 VCC 2.5 V input
A7 BE0 BE0 input
A8 MP_CLK Three-wire serial bus CLK input
A9 DEO Data enable input
A10 HSYO Horizontal sync input
A11 VCC2.5 VCC 2.5 V input
A12 OFL2 Dimmer control signal output 2
A13 BO0 BO0 input
A14 OFL1 Dimmer control signal output 1
A15 TD0 NC
A16 GND GND
B1 RE2 RE2 input
B2 GND GND
B3 PROG_B CONFIG reset input
B4 BE4 BE4 input
B5 BE3 BE3 input
B6 BE2 BE2 input
B7 BE1 BE1 input
B8 PNLCLK CLK input
B9 GND GND
B10 BO4 BO4 input
B11 BO3 BO3 input
B12 BO2 BO2 input
B13 BO1 BO1 input
B14 VSYO Vertical sync input
B15 GND GND
B16 FREERUN FREERUN switching input
C1 RE0 RE0 input
C2 RE1 RE1 input
C3 GE0 GE0 input
C4 HSWAP_EN Pull-up
C5 BE7 BE7 input
C6 BE6 BE6 input
C7 BE5 BE5 input
C8 GO2 GO2 input
C9 GCK2 CLK input 2
C10 GO1 GO1 input
C11 BO6 BO6 input
C12 BO5 BO5 input
C13 TMS Pull-up
C14 TCK Pull-up
C15 RO3 RO3 input
C16 RO0 RO0 input
D1 RE4 RE4 input
D2 RE3 RE3 input
Pin No Terminal Name I/O Description
