PinNo TerminalName I/O Description 

PinNo TerminalName I/O Description
101 OGND GND 102 ODCK_D Delay clock output 103 GND GND 104 DVCC 2.5 V 105 TPCLK Not used 106 PWM1 Not used 107 PWM0 Not used 108 BUT0+ Not used 109 BUT0- Not used 110 BUT1+ Not used 111 BUT1- Not used 112 TMDS_SEL Panel link/parallel selection input 113 DVCC 2.5 V 114 GND GND 115 NC Not used 116 NC Not used 117 OO2 ODD B2 output 118 OO3 ODD B3 output 119 OO4 ODD B4 output 120 OO5 ODD B5 output 121 OO6 ODD B6 output 122 OO7 ODD B7 output 123 OVCC 3.3 V 124 OGND GND 125 OO8 ODD G0 output 126 OO9 ODD G1 output 127 OO10 ODD G2 output 128 OO11 ODD G3 output 129 OO12 ODD G4 output 130 OO13 ODD G5 output 131 OO14 ODD G6 output 132 OO15 ODD G7 output 133 NC Not used 134 NC Not used 135 OVCC 3.3 V 136 OGND GND 137 DVCC 2.5 V 138 GND GND 139 OO16 ODD R0 output 140 OO17 ODD R1 output 141 OO18 ODD R2 output 142 OO19 ODD R3 output 143 OO20 ODD R4 output 144 OO21 ODD R5 output 145 OO22 ODD R6 output 146 NC Not used 147 DVCC 2.5 V 148 GND GND 149 KEY_SDA SDA for HDCP KEY EEPROM 150 KEY_SCL SCL for HDCP KEY EEPROM
151 DDC_SDA SDA for DDC EEPROM 152 DDC_SCL SCL for DDC EEPROM 153 GND GND 154 XTAL1 GND 155 XTZL2 Not used 156 GND GND 157 OGND GND 158 OO23 ODD R7 output 159 OVCC 3.3 V 160 GND GND 161 XCLK External clock input 162 GND GND 163 DVCC 2.5 V 164 MSTATE I2C master output 165 SCL Config SCL 166 SDA Config SDA 167 PGND GND 168 PVCC 3.3 V 169 AGND GND 170 AVDD 3.3 V 171 TX_3+ Not used 172 TX_3- Not used 173 TX_CK+ Not used 174 TX_CK- Not used 175 TX_2+ Not used 176 TX_2- Not used 177 AGND GND 178 AVDD 3.3 V 179 TX_1+ Not used 180 TX_1- Not used 181 TX_0+ Not used 182 TX_0- Not used 183 PVCC 3.3 V 184 PGND GND 185 AGND GND 186 RX2+ TMDS RX2+ signal input 187 RX2- TMDS RX2- signal input 188 AVCC 3.3 V 189 AGND GND 190 AVCC 3.3 V 191 RX1+ TMDS RX1+ signal input 192 RX1- TMDS RX1- signal input 193 AGND GND 194 AVDD 3.3 V 195 AGND GND 196 RX0+ TMDS RX0+ signal input 197 RX0- TMDS RX0- signal input 198 AGND GND 199 RXC+ TMDS RXC+ signal input 200 RXC- TMDS RXC- signal input


