LC-32G4U/G4D
LC-37G4U/G4D
IC2206 (SII861) DVI receiver Terminal function
  

PinNo TerminalName I/O Description 1 GND GND  2 DVCC 2.5V  3 RESET# Resetinput  4 PD# Powerdownmodeinput  5 STDBY/PWM0 Notused  6 SUSPD/ORNG Notused  7 ONOFF/LSYNC# Syncsignaljudgmentoutput  8 TSTMD GND  9 TSTEN GND  10 GND GND  11 DVCC 2.5V  12 OVCC 3.3V  13 OGND GND  14 NC Notused  15 NC Notused  16 OE0 EVENB0output 17 OE1 EVENB1output 18 OE2 EVENB2output 19 OE3 EVENB3output 20 OE4 EVENB4output 21 OE5 EVENB5output 22 OE6 EVENB6output 23 OE7 EVENB7output 24 OVCC 3.3V 25 OGND GND 26 GND GND 27 DVCC 2.5V 28 OE8 EVENG0output 29 OE9 EVENG1output 30 OE10 EVENG2output 31 OE11 EVENG3output 32 OE12 EVENG4output 33 OE13 EVENG5output 34 NC Notused 35 NC Notused 36 NC Notused 37 PD23 Notused 38 PD22 Notused 39 PD21 Notused 40 PD20 Notused 41 PD19 Notused 42 PD18 Notused 43 PD17 Notused 44 PD16 Notused 45 PD15 Notused 46 PD14 Notused 47 PD13 Notused 48 PD12 Notused 49 PD11 Notused 50 PD10 Notused
51 PD9 Notused 52 PD8 Notused 53 PD7 Notused 54 PD6 Notused 55 PD5 Notused 56 PD4 Notused 57 PD3 Notused 58 PD2 Notused 59 PD1 Notused 60 PD0 Notused 61 PDE Notused 62 PHS Notused 63 PVS Notused 64 PCLK Notused 65 OGND GND 66 NC Notused 67 NC Notused 68 NC Notused 69 OGND GND 70 ADE Notused 71 NC Notused 72 NC Notused 73 OE14 EVENG6output 74 OE15 EVENG7output 75 DVCC 2.5V 76 GND GND 77 OGND GND 78 OVCC 3.3V 79 OE16 EVENR0output 80 OE17 EVENR1output 81 OE18 EVENR2output 82 OE19 EVENR3output 83 OE20 EVENR4output 84 OE21 EVENR5output 85 OE22 EVENR6output 86 OE23 EVENR7output 87 DVCC 2.5V 88 GND GND 89 CTL1/IVS Notused 90 CTL2/HIS Notused 91 CTL3/IDE Notused 92 OVCC 3.3V 93 ODCK Clockoutput 94 OGND GND 95 DE Dataenableoutput 96 VSYNC Verticalsyncsignaloutput 97 HSYNC Horizontalsyncsignaloutput 98 OO0 ODDB0output 99 OO1 ODDB1output 100 NC Notused
PinNo TerminalName I/O Description


