Pin No Terminal Name I/O Description
1 B24 B data input
2 B25 B data input
3 VCC Power supply
4 GND GND
5 B26 B data input
6 B27 B data input
7 HSYNC Horizontal sync signal input
8 VSYNC Vertical sync signal input
9 DE Data enable input
10 CLKIN Clock input
11 R/F Clock trigger switching terminal
12 RS Amplitude switching
13 TEST1 Test terminal
14 TEST2 Test terminal
15 MODE1 Mode switching terminal
16 MODE0 Mode switching terminal
17 OE Output enable terminal
18 6/8 Bit selection terminal
19 /PDWN Power down terminal
20 TEST3 Test terminal
21 TEST4 Test terminal
22 TEST5 Test terminal
23 PLL GND PLLGND terminal
24 PLL VCC PLL power supply terminal
25 PLL GND PLLGND terminal
26 LVDS GND LVDS output GND
27 TD2+ LVDS output
28 TD2- LVDS output
29 TCLK2+ LVDS CLK output
30 TCLK2- LVDS CLK output
31 TC2+ LVDS output
32 TC2- LVDS output
33 LVDS VCC LVDS output power supply terminal
34 TB2+ LVDS output
35 TB2- LVDS output
36 TA2+ LVDS output
37 TA2- LVDS output
38 LVDS GND LVDS output GND
39 TD1+ LVDS output
40 TD1- LVDS output
41 TCLK1+ LVDS CLK output
42 TCLK1- LVDS CLK output
43 TC1+ LVDS output
44 TC1- LVDS output
45 LVDS VCC LVDS output power supply terminal
46 TB1+ LVDS output
47 TB1- LVDS output
48 TA1+ LVDS output
49 TA1- LVDS output
50 LVDS GND LVDS output GND
