Sharp LC-32G4U - Page 39

39
LC-32G4U/G4D
LC-37G4U/G4D




Pin No Terminal Name I/O Description
1 PLL GND PLL GND 2 PLL VCC PLL power supply terminal 3 GND GND 4 /PDWN Power down terminal 5 MODE0 Mode switching terminal 6 MODE1 Mode switching terminal 7 GND GND 8 R/F Clock trigger switching terminal 9 DRVSEL Output drive switching 10 R20 R data output 11 R21 R data output 12 R22 R data output 13 R23 R data output 14 R24 R data output 15 VCC Power supply terminal 16 GND GND 17 R25 R data output 18 R26 R data output 19 R27 R data output 20 G20 G data output 21 G21 G data output 22 G22 G data output 23 G23 G data output 24 G24 G data output 25 G25 G data output 26 G26 G data output 27 VCC Power supply terminal 28 GND GND 29 G27 G data output 30 B20 B data output 31 B21 B data output 32 B22 B data output 33 VCC Power supply terminal 34 GND GND 35 B23 B data output 36 B24 B data output 37 B25 B data output 38 B26 B data output 39 B27 B data output 40 CLKOUT Clock output 41 VCC Power supply terminal 42 GND GND 43 R10 R data output 44 R11 R data output 45 R12 R data output 46 R13 R data output 47 R14 R data output 48 VCC Power supply terminal 49 GND GND 50 R15 R data output




Pin No Terminal Name I/O Description
51 R16 R data output 52 R17 R data output 53 G10 G data output 54 G11 G data output 55 G12 G data output 56 VCC Power supply terminal 57 GND GND 58 G13 G data output 59 G14 G data output 60 G15 G data output 61 G16 G data output 62 G17 G data output 63 B10 B data output 64 B11 B data output 65 B12 B data output 66 B13 B data output 67 B14 B data output 68 B15 B data output 69 VCC Power supply terminal 70 GND GND 71 B16 B data output 72 B17 B data output 73 HSYNC Horizontal sync output 74 VSYNC Vertical sync output 75 DE Data enable output 76 LVDS GND LVDS input GND 77 RA1- LVDS input 78 RA1+ LVDS input 79 RB1- LVDS input 80 RB1+ LVDS input 81 LVDS VCC LVDS input power supply terminal 82 RC1- LVDS input 83 RC1+ LVDS input 84 RCLK1- LVDS CLK input 85 RCLK1+ LVDS CLK input 86 RD1- LVDS input 87 RD1+ LVDS input 88 LVDS GND LVDS input GND 89 RA2- LVDS input 90 RA2+ LVDS input 91 RB2- LVDS input 92 RB2+ LVDS input 93 LVDS VCC LVDS input power supply terminal 94 RC2- LVDS input 95 RC2+ LVDS input 96 RCLK2- LVDS CLK input 97 RCLK2+ LVDS CLK input 98 RD2- LVDS input 99 RD2+ LVDS input 100 LVDS GND LVDS input GND
IC4602 (TLVD824) LVDS receiver Terminal function
