Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
DUNTKC268VJ04 (LC-32G4U/G4D)
DUNTKC268VJ03 (LC-37G4U/G4D)
LCD CONT Unit(Continued)
FB2007 RBLN-A005WJZZY J Ferrite Bead AA
FB2008 RBLN-A005WJZZY J Ferrite Bead AA
FB2009 RBLN-A005WJZZY J Ferrite Bead AA
FB2021 RBLN-A005WJZZY J Ferrite Bead AA
FB2022 RBLN-A005WJZZY J Ferrite Bead AA
FB2023 RBLN-A005WJZZY J Ferrite Bead AA
FB4101 RBLN-0252TAZZY J Ferrite Bead AA
FB4102 RBLN-0252TAZZY J Ferrite Bead AA
FB4501 RBLN-0095CEZZY J Ferrite Bead AD
FB4502 RBLN-0095CEZZY J Ferrite Bead AD
FB4504 RBLN-0095CEZZY J Ferrite Bead AD
FB4601 RBLN-0060TAZZY J Ferrite Bead AB
FB4602 RBLN-0060TAZZY J Ferrite Bead AB
FB4603 RBLN-0060TAZZY J Ferrite Bead AB
FB4701 RBLN-0095CEZZY J Ferrite Bead AD
FB4702 RBLN-0095CEZZY J Ferrite Bead AD
FB4901 RBLN-0095CEZZY J Ferrite Bead AD
FB4902 RBLN-0095CEZZY J Ferrite Bead AD
FB7705 RBLN-A005WJZZY J Ferrite Bead AA
FB7706 RBLN-0252TAZZY J Ferrite Bead AA
FB7708 RBLN-0252TAZZY J Ferrite Bead AA
FB7709 RBLN-A005WJZZY J Ferrite Bead AA
FB7710 RBLN-0210TAZZY J Ferrite Bead AB
FB7711 RBLN-0252TAZZY J Ferrite Bead AA
FB7712 RBLN-A005WJZZY J Ferrite Bead AA
FB7713 RBLN-A005WJZZY J Ferrite Bead AA
FB7716 RBLN-A005WJZZY J Ferrite Bead AA
FB7717 RBLN-A005WJZZY J Ferrite Bead AA
FB7718 RBLN-A005WJZZY J Ferrite Bead AA
FB7719 RBLN-A005WJZZY J Ferrite Bead AA
FB7720 RBLN-0252TAZZY J Ferrite Bead AA
P2001 QPLGN0544FJZZY J Plug, 7Pin AD
P2002 QPLGNA059WJZZ J Plug, 5Pin AC
P2004 QPLGNA048WJZZ J Plug, 9Pin AC
P4501 QPLGN0547FJZZY J Plug, 10Pin AE
P7704 QPLGNA062WJZZ J Plug, 8Pin AC
P7705 QPLGNA066WJZZ J Plug, 12Pin AD
P7706 QPLGN0175FJZZY J Plug, 3Pin AC
P7708 QPLGN0175FJZZY J Plug, 3Pin AC
P7709 QPLGNA047WJZZ J Plug, 8Pin AC
SC2001 QSOCN0490FJZZY J Socket, 30Pin AF
SC4601 QSOCN0491FJZZY J Socket, 33Pin AF
SC4651 QSOCNA222WJZZY J Socket, 80Pin AH
SC4652 QSOCNA222WJZZY J Socket, 80Pin AH
LUG7701 QLUGHA006WJZZY J Lug AC
LUG7702 QLUGHA006WJZZY J Lug AC
LUG7703 QLUGHA006WJZZY J Lug AC
LUG7704 QLUGHA006WJZZY J Lug AC
LUG7705 QLUGHA006WJZZY J Lug AC
LUG7706 QLUGHA006WJZZY J Lug AC
DUNTKC269VJ04 (LC-32G4U/G4D)
DUNTKC269VJ03 (LC-37G4U/G4D)
TMDS RX Unit
INTEGRATED CIRCUITS
IC2201 VHiTC7W34U/-1Y J TC7W34FU AE
IC2203 VHiBR24C01F-1Y J BR24C01AF-WE2 AE
IC2204 VHiPST9221N-1Y J PST9221NR AE
IC2205 VHiPST9228N-1Y J PST9228NR AE
IC2206 VHiSii861++-1Q J SII861CM208 BE
IC2208 VHiM24C32WN-1Y J M24C32-WMN6T AG
IC2301 VHiPQ1R33//-1Y J PQ1R33 AE
IC2302 VHiTLVD823+-1Q J THC63LVD823 AY
IC7801 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC7802 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
TRANSISTORS
Q2201 VSDTC114EE/-1Y J DTC114EE AB
Q2202 VS2SK536///-1Y J 2SK536 AE
Q2203 VSDTA114EE/-1Y J DTA114EE AB
Q2204 VS2SK536///-1Y J 2SK536 AE
Q2205 VSDTC114EE/-1Y J DTC114EE AB
Q2206 VSDTC114EE/-1Y J DTC114EE AB
Q2207 VSDTA114EE/-1Y J DTA114EE AB
Q2208 VSDTC114EE/-1Y J DTC114EE AB
Q2209 VS2SA1530AR-1Y J 2SA1530AR AB
Q2210 VSDTC114EE/-1Y J DTC114EE AB
Q2211 VSDTC114EE/-1Y J DTC114EE AB
Q2212 VS2SA1530AR-1Y J 2SA1530AR AB
Q2213 VSDTC114EE/-1Y J DTC114EE AB
Q2214 VSDTC114EE/-1Y J DTC114EE AB
Q2215 VSDTC114EE/-1Y J DTC114EE AB
Q2216 VSDTA114EE/-1Y J DTA114EE AB
Q2217 VS2SK536///-1Y J 2SK536 AE
Q2218 VS2SK536///-1Y J 2SK536 AE
Q2220 VSDTC114EE/-1Y J DTC114EE AB
DIODES AND LED'S
D2201 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2202 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2203 VHDDA221///-1Y J DA221 AB
D2204 VHDDAN202K/-1Y J DAN202K AB
D2205 VHDDA221///-1Y J DA221 AB
D2206 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2207 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2208 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2209 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2210 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2211 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2212 VHDHSU119//-1Y J HSU119 AB
D2213 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2214 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2215 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2216 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2217 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2218 VHDHSU119//-1Y J HSU119 AB
D2219 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2220 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2225 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2226 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2301 VHD1SS355//-1Y J 1SS355 AB
D7801 VHDSFPB54//2EY J SFPB54 AC
D7802 VHDSFPB54//2EY J SFPB54 AC
FILTERS
FL2201 RFiLNA087WJZZY J Filter AD
FL2202 RFiLNA087WJZZY J Filter AD
FL2203 RFiLNA087WJZZY J Filter AD
FL2204 RFiLNA087WJZZY J Filter AD
FL2205 RFiLNA087WJZZY J Filter AD
FL2206 RFiLNA087WJZZY J Filter AD
FL2207 RFiLNA087WJZZY J Filter AD
FL2208 RFiLNA087WJZZY J Filter AD
