112
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
FL2209 RFiLNA087WJZZY J Filter AD
FL2210 RFiLNA087WJZZY J Filter AD
FL2211 RFiLNA087WJZZY J Filter AD
FL2212 RFiLNA087WJZZY J Filter AD
FL2213 RFiLNA087WJZZY J Filter AD
FL2214 RFiLNA087WJZZY J Filter AD
FL2215 RFiLNA087WJZZY J Filter AD
COILS
L7801 RCiLP0302TAZZY J Coil, 150uH AE
L7803 RCiLP0303TAZZY J Coil, 220uH AG
L7804 RCiLP0343TAZZY J Coil, 10uH AD
CAPACITORS
C2201 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2203 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2204 VCEASX1EN336MY J 33 25V Electrolytic AC
C2205 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2206 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2207 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2208 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2209 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2210 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2213 VCEASX1CN476MY J 47 16V Electrolytic AC
C2214 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2215 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2216 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2217 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2218 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2219 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2220 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2221 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2222 VCKYCY1HB682KY J 6800p 50V Ceramic AA
C2223 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2224 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2225 VCCCCY1HH471JY J 470p 50V Ceramic AA
C2227 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2228 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2229 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2230 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2231 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2232 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2233 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2234 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2235 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C2236 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2237 VCCCCY1HH471JY J 470p 50V Ceramic AA
C2242 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2243 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2244 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2245 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2247 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2248 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2249 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2250 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2251 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2252 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2253 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2254 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2256 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2259 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2260 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2261 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2262 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2263 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2264 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2265 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2266 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2268 VCKYCY1HB103KY J 0.01 50V Ceramic AA
DUNTKC269VJ04 (LC-32G4U/G4D)
DUNTKC269VJ03 (LC-37G4U/G4D)
TMDS RX Unit(Continued)
C2269 VCCCCY1HH331JY J 330p 50V Ceramic AA
C2270 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2271 VCKYCY0JB105KY J 1 6.3V Ceramic AC
C2272 VCKYCY1AB474KY J 0.47 10V Ceramic AC
C2273 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2274 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2275 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2276 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2277 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2278 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2279 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2280 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2281 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2282 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2301 VCEASX1CN476MY J 47 16V Electrolytic AC
C2302 VCEASX1CN476MY J 47 16V Electrolytic AC
C2303 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2304 VCEASX1CN476MY J 47 16V Electrolytic AC
C2305 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2306 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2307 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2308 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2309 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2310 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2311 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2312 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2313 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2314 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2315 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2316 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2317 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7801 VCEASY1EN227MY J 220 25V Electrolytic AD
C7802 VCEASY1EN227MY J 220 25V Electrolytic AD
C7803 VCCCCY1HH681JY J 680p 50V Ceramic AB
C7804 VCCCCY1HH681JY J 680p 50V Ceramic AB
C7805 VCEASY1CN477MY J 470 16V Electrolytic AD
C7806 VCEASY1CN477MY J 470 16V Electrolytic AD
C7807 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
RESISTORS
R2201 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2202 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2203 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2205 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2206 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2209 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2210 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2212 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2213 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2214 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2215 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2216 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2217 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2218 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2219 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2220 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2222 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2228 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2229 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2230 VRS-CY1JF473FY J 47k 1/16W Metal Oxide AA
R2231 VRS-CY1JF473FY J 47k 1/16W Metal Oxide AA
R2232 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2233 VRS-CY1JF100FY J 10 1/16W Metal Oxide AB
R2234 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2235 VRS-CY1JF100FY J 10 1/16W Metal Oxide AB
R2238 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R2239 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R2240 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2242 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2244 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2245 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2246 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2247 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2248 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2249 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
