113
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
R2251 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2252 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2253 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R2254 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R2256 VRK-CD1JJ680JY J 68 1/16W Metal Compo. AC
R2257 VRK-CD1JJ680JY J 68 1/16W Metal Compo. AC
R2258 VRS-CH1JF680JY J 68 1/16W Metal Oxide AA
R2259 VRS-CJ1JF680JY J 68 1/16W Metal Oxide AA
R2260 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2261 VRS-CY1JF511JY J 510 1/16W Metal Oxide AA
R2262 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2264 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2265 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2266 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2267 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2268 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2269 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2270 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2273 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2274 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2275 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2276 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R2278 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R2279 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2280 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2281 VRK-CD1JJ680JY J 68 1/16W Metal Compo. AC
R2282 VRS-CH1JF680JY J 68 1/16W Metal Oxide AA
R2283 VRS-CJ1JF680JY J 68 1/16W Metal Oxide AA
R2284 VRK-CD1JJ680JY J 68 1/16W Metal Compo. AC
R2285 VRS-CJ1JF680JY J 68 1/16W Metal Oxide AA
R2286 VRS-CH1JF680JY J 68 1/16W Metal Oxide AA
R2287 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2288 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2289 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2291 VRS-CJ1JF680JY J 68 1/16W Metal Oxide AA
R2292 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2293 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2297 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2298 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2314 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2315 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2317 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2318 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R7801 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R7802 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R7803 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R7804 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R7805 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R7806 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R7807 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R7808 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB2201 RBLN-0006TAZZY J Ferrite Bead AB
FB2203 RBLN-0210TAZZY J Ferrite Bead AB
FB2204 RBLN-0210TAZZY J Ferrite Bead AB
FB2205 RBLN-0006TAZZY J Ferrite Bead AB
FB2206 RBLN-0006TAZZY J Ferrite Bead AB
FB2207 RBLN-0210TAZZY J Ferrite Bead AB
FB2209 RBLN-0006TAZZY J Ferrite Bead AB
FB2211 RBLN-A005WJZZY J Ferrite Bead AA
FB2212 RBLN-A005WJZZY J Ferrite Bead AA
FB2218 RBLN-A005WJZZY J Ferrite Bead AA
FB2302 RBLN-0060TAZZY J Ferrite Bead AB
FB2303 RBLN-0060TAZZY J Ferrite Bead AB
FB2304 RBLN-0060TAZZY J Ferrite Bead AB
FB2305 RBLN-0060TAZZY J Ferrite Bead AB
FB2306 RBLN-0060TAZZY J Ferrite Bead AB
FB7801 RBLN-0252TAZZY J Ferrite Bead AA
FB7802 RBLN-0252TAZZY J Ferrite Bead AA
DUNTKC269VJ04 (LC-32G4U/G4D)
DUNTKC269VJ03 (LC-37G4U/G4D)
TMDS RX Unit(Continued)
J2201 QSOCDA016WJZZ J Socket, 8Pin AG
P2201 QPLGNA043WJZZ J Plug, 4Pin AB
P7801 QPLGNA046WJZZ J Plug, 7Pin AC
P7802 QPLGNA047WJZZ J Plug, 8Pin AC
SC2201 QSOCZA017WJZZ J Socket, 34Pin AM
SC2202 QSOCZ2015CEZZ J Socket, 22Pin AG
SC2203 QSOCN0490FJZZY J Socket, 30Pin AF
SC2301 QSOCN0491FJZZY J Socket, 33Pin AF
LUG2201 QLUGHA006WJZZY J Lug AC
LUG2202 QLUGHA006WJZZY J Lug AC
LUG2203 QLUGHA006WJZZY J Lug AC
LUG2204 QLUGHA006WJZZY J Lug AC
LUG2205 QLUGHA006WJZZY J Lug AC
LUG2206 QLUGHA006WJZZY J Lug AC
X2201 RCRUAA034WJZZY J 16.713MHz AL
GCOVAA685WJKB J Cover AG
DUNTKC274UJ02
KEY Unit
DIODES
D151 RH-EXA092WJZZY J Zener Diode, 12V AB
D152 RH-EXA092WJZZY J Zener Diode, 12V AB
D153 RH-EXA092WJZZY J Zener Diode, 12V AB
RESISTORS
R151 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R152 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R153 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
SWITCHES
S151 QSW-K0095CEZZ J CH (ù)AB
S152 QSW-K0095CEZZ J CH (Ù)AB
S153 QSW-K0095CEZZ J INPUT AB
S154 QSW-K0095CEZZ J VOL (+) AB
S155 QSW-K0095CEZZ J VOL (–) AB
S156 QSW-K0095CEZZ J POWER AB
S157 QSW-P0591CEZZ J MAIN POWER AQ
MISCELLANEOUS PARTS
P151 QPLGN0564TAZZY J Plug, 5Pin AC
P153 QPLGNA007WJZZ J Plug, 10Pin AE
