114
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
RDENCA058WJZZ (LC-32/37G4U)
RDENCA059WJZZ (LC-32/37G4D)
POWER SUPPLY Unit
DUNTKC275UJ02
R/C LED Unit
INTEGRATED CIRCUIT
IC101 VHiTPS850++-1Y J TPS850 AG
TRANSISTORS
Q102 VS2SC2712Y/-1Y J 2SC2712Y AB
Q103 VS2SC2712Y/-1Y J 2SC2712Y AB
Q104 VS2SC3928AR-1Y J 2SC3928AR AB
Q105 VS2SC3928AR-1Y J 2SC3928AR AB
DIODES AND LED'S
D101 RH-EXA092WJZZY J Zener Diode, 12V AB
D103 RH-PX0421CEZZY J PhotoDiode AD
CAPACITORS
C101 VCEASX0JN107MY J 100 6.3V Electrolytic AC
C102 VCKYTV1CF225ZY J 2.2 16V Ceramic AB
C104 VCEASX1CN106MY J 10 16V Electrolytic AC
C105 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
RESISTORS
R101 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R104 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R105 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R106 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R108 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R109 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R117 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
P101 QPLGN0874TAZZY J Plug, 8Pin AD
RMC101 RRMCU0239CEZZ J Remote Receiver AG
SLD101 PSLDM4646CEFW J Shield AD
DUNTKC276UJ02
SP TERMINAL Unit
MISCELLANEOUS PARTS
P202 QPLGNA058WJZZ J Plug, 4Pin AC
P203 QTANAA005WJZZ J Terminal, 4Pin AG
INTEGRATED CIRCUITS
IC2701 95CH1151AS001 J MIP0255SPSCF AV
IC2702 95CH3151AC001 J FA5502M-TE1 AZ
IC2751 95CH10Q3AQ001 J TA76431 AL
IC3751 95CH10Q3AQ001 J TA76431 AL
IC4751 95CH10Q3AQ001 J TA76431 AL
TRANSISTORS
Q2701 95CT2843KL001 J 2SK2843 AU
Q2702 95CT2843KL001 J 2SK2843 AU
Q2703 95CT1858DR001 J 2SD1858 AH
Q2704 95CT1237BR001 J 2SB1237 AH
Q2705 95CT1576AC002 J 2SA1576A AD
Q2706 95CT4081CC002 J 2SC4081 AD
Q2707 95CT1443BR002 J 2SB1443 TV2 AL
Q2708 95CT1576AC002 J 2SA1576A AD
Q2709 95CT4081CC002 J 2SC4081 AD
Q2751 95CT4081CC002 J 2SC4081 AD
Q2752 95CT1577AC002 J 2SA1577 AE
Q2755 95CT4081CC002 J 2SC4081 AD
Q3701 95CT4081CC002 J 2SC4081 AD
Q3702 95CT4081CC002 J 2SC4081 AD
Q3703 95CT3326KL002 J 2SK3326(2) AQ
Q3704 95CT3326KL002 J 2SK3326(2) AQ
Q3705 95CT4097CC002 J 2SC4097 AE
Q3706 95CT4097CC002 J 2SC4097 AE
Q4701 95CT4081CC002 J 2SC4081 AD
Q4702 95CT4081CC002 J 2SC4081 AD
Q4703 95CT3326KL002 J 2SK3326(2) AQ
Q4704 95CT3326KL002 J 2SK3326(2) AQ
Q4705 95CT4097CC002 J 2SC4097 AE
Q4706 95CT4097CC002 J 2SC4097 AE
DIODES
å D2701 95CD1132AL006 J D25XB60 AU
å D2702 95CD1057AQ006 J ERA15-06 AE
åD2703 95CD1057AQ006 J ERA15-06 AE
D2704 95CD2095AQ008 J 1SS355 AD
D2706 95CD2172AL006 J SF10L60U AR
D2707 95CD2067AQ006 J ERA22-06 AF
D2708 95CD2067AQ010 J ERA22-10 AG
D2709 95CD4091AQ005 J Zener Diode UDZ 3.0B AF
D2710 95CD4091AQ025 J Zener Diode UDZ 20B AF
D2711 95CD2095AQ008 J 1SS355 AD
D2712 95CD2071AQ002 J ERA92-02 AG
D2713 95CD4091AQ025 J Zener Diode UDZ 20B AF
D2714 95CD4091AQ028 J Zener Diode UDZ 27B AF
D2715 95CD2095AQ008 J 1SS355 AD
D2716 95CD4092AQ002 J Zener Diode UDZS 5.6B AE
D2751 95CD2005BQ206 J ERC81-006 AL
D2752 95CD4092AQ002 J Zener Diode UDZS 5.6B AE
D2753 95CD2095AQ008 J 1SS355 AD
D2754 95CD4091AQ024 J Zener Diode UDZ 18B AF
D2755 95CD2095AQ008 J 1SS355 AD
D2756 95CD4091AQ024 J Zener Diode UDZ 18B AF
D2757 95CD2095AQ008 J 1SS355 AD
D2758 95CD3114AC004 J MA1070000L
D3701 95CD4092AQ007 J Zener Diode UDZ S 9.1B AE
D3702 95CD4092AQ004 J Zener Diode UDZS 6.8B AE
D3703 95CD2095AQ008 J 1SS355 AD
D3704 95CD2095AQ008 J 1SS355 AD
D3705 95CD2095AQ008 J 1SS355 AD
D3706 95CD4061AQ320 J Zener Diode HZ-30CP
D3707 95CD4061AQ320 J Zener Diode HZ-30CP
D3708 95CD4092AQ004 J Zener Diode UDZS 6.8B AE
D3709 95CD2095AQ008 J 1SS355 AD
D3710 95CD2095AQ008 J 1SS355 AD
D3711 95CD2095AQ008 J 1SS355 AD
D3712 95CD2095AQ008 J 1SS355 AD
D3713 95CD2095AQ008 J 1SS355 AD
