115
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
D3714 95CD2095AQ008 J 1SS355 AD
D3751 95CD2027BQ006 J YG805C06R AP
D3752 95CD2027BQ006 J YG805C06R AP
D3753 95CD2027BQ006 J YG805C06R AP
D4701 95CD4092AQ007 J Zener Diode UDZ S 9.1B AE
D4702 95CD4092AQ004 J Zener Diode UDZS 6.8B AE
D4703 95CD2095AQ008 J 1SS355 AD
D4704 95CD2095AQ008 J 1SS355 AD
D4705 95CD2095AQ008 J 1SS355 AD
D4706 95CD4061AQ320 J Zener Diode HZ-30CP
D4707 95CD4061AQ320 J Zener Diode HZ-30CP
D4708 95CD4092AQ004 J Zener Diode UDZS 6.8B AE
D4709 95CD2095AQ008 J 1SS355 AD
D4710 95CD2095AQ008 J 1SS355 AD
D4711 95CD2095AQ008 J 1SS355 AD
D4712 95CD2095AQ008 J 1SS355 AD
D4713 95CD2095AQ008 J 1SS355 AD
D4714 95CD2095AQ008 J 1SS355 AD
D4751 95CD2027BQ006 J YG805C06R AP
D4752 95CD2027BQ006 J YG805C06R AP
D4753 95CD2027BQ006 J YG805C06R AP
Z2701 95CD7058AQ471 J Zener Diode ENC471 AG
COILS
åL2701 95CL1197RS602 J Coil SC-02-E60JH-A AQ
or SC-02-E60JKH
åL2702 95CL1197RS602 J Coil SC-02-E60JH-A AQ
or SC-02-E60JKH
åL2703 95CL1197RS602 J Coil SC-02-E60JH-A AQ
or SC-02-E60JKH
L2704 95CL1185RS640 J Coil SN12-400JH AR
L2705 95CL1184RS401 J Coil SHB-03-401JH AY
L2706 95CL1184RS401 J Coil SHB-03-401JH AY
TRANSFORMERS
åT2701 95CL2000BS040 J 2BS040 AT
åT3701 95CL2000MS018 J 2MS018 AZ
åT4701 95CL2000MS018 J 2MS018 AZ
CAPACITORS
åC2703 95CC1076QQ222 J VA3 2200p Ceramic AE
(LC-32/37G4U)
åC2703 95CC1076QQ152 J VA3 1500p Ceramic
(LC-32/37G4D)
å C2704 95CC1076QQ222 J VA3 2200p Ceramic AE
(LC-32/37G4U)
åC2704 95CC1076QQ152 J VA3 1500p Ceramic
(LC-32/37G4D)
å C2705 95CC2045QQ104 J 0.1(RE-C)AC250V Film AF
åC2706 95CC1076QQ102 J VA3 1000p Ceramic AE
åC2707 95CC1076QQ102 J VA3 1000p Ceramic AE
åC2708 95CC1076QQ222 J VA3 2200p Ceramic AE
(LC-32/37G4U)
å C2708 95CC1076QQ152 J VA3 1500p Ceramic
(LC-32/37G4D)
åC2709 95CC1076QQ102 J VA3 1000p Ceramic AE
C2710 95CC2047MQ224 J 0.22 450V Film AN
C2711 95CC2047MQ224 J 0.22 450V Film AN
C2712 95CC2047MQ224 J 0.22 450V Film AN
C2713 95CC2047MQ224 J 0.22 450V Film AN
C2714 95CC1101RR101 J 100p 1kV Ceramic AD
åC2715 95CC2045QQ104 J 0.1(RE-C)AC250V Film AF
C2716 95CC1101RR101 J 100p 1kV Ceramic AD
C2717 95CC3138YR100 J 10(KMQ) 450V Electrolytic
C2718 95CC3138YR100 J 10(KMQ) 450V Electrolytic
C2719 95CC10A9RQ102 J 1000p 1kV Ceramic AE
C2720 95CC1095EQ104 J 0.1 50V Ceramic AC
C2721 95CC10B2SQ470 J 47p 2kV Ceramic AD
C2722 95CC1095EQ473 J 0.047 50V Ceramic AC
C2724 95CC1094EQ471 J 470p 50V Ceramic AC
C2725 95CC1095EQ104 J 0.1 50V Ceramic AC
C2726 95CC1094EQ101 J 100p 50V Ceramic AC
C2727 95CC1094EQ471 J 470p 50V Ceramic AC
C2728 95CC1095EQ104 J 0.1 50V Ceramic AC
C2729 95CC1095EQ104 J 0.1 50V Ceramic AC
C2730 95CC1095EQ104 J 0.1 50V Ceramic AC
C2731 95CC1095EQ103 J 0.01 50V Ceramic AC
C2732 95CC1095EQ104 J 0.1 50V Ceramic AC
C2733 95CC10Q0CQ105 J 1 25V Ceramic AE
C2734 95CC10Q0CQ105 J 1 25V Ceramic AE
C2735 95CC1094EQ102 J 1000p 50V Ceramic AD
C2736 95CC30A0EQ221 J 220(ZL) 50V Electrolytic AK
C2737 95CC10Q0CQ105 J 1 25V Ceramic AE
åC2738 95CC2045QQ104 J 0.1(RE-C)AC250V Film AF
C2739 95CC2047MQ224 J 0.22 450V Film AN
C2741 95CC1095EQ104 J 0.1 50V Ceramic AC
åC2749 95CC1076QQ222 J 2200p VA3 Ceramic AE
(LC-32/37G4U)
å C2749 95CC1076QQ102 J 1000p VA3 Ceramic AE
(LC-32/37G4D)
åC2750 95CC1076QQ222 J 2200p VA3 Ceramic AE
(LC-32/37G4U)
å C2750 95CC1076QQ102 J 1000p VA3 Ceramic AE
(LC-32/37G4D)
C2751 95CC10A9RQ102 J 1000p 1kV Ceramic AE
C2752 95CC30A0DQ331 J 330(ZL) 35V Electrolytic AH
C2753 95CC30A0DQ331 J 330(ZL) 35V Electrolytic AH
C2754 95CC1095EQ104 J 0.1 50V Ceramic AC
C2755 95CC1095EQ104 J 0.1 50V Ceramic AC
C2758 95CC1095EQ103 J 0.01 50V Ceramic AC
C3701 95CC3042MQ820 J 82(KMG) 450V Electrolytic AU
C3703 95CC2047MQ224 J 0.22 450V Film AN
C3705 95CC1093AQ472 J 4700p 50V Ceramic AE
C3706 95CC1094EQ222 J 2200p 50V Ceramic AE
C3707 95CC1094EQ101 J 100p 50V Ceramic AC
C3708 95CC1095EQ103 J 0.01 50V Ceramic AC
C3709 95CC1093AQ472 J 4700p 50V Ceramic AE
C3749 95CC1076QQ222 J 2200p VA3 Ceramic AE
(LC-32/37G4U)
C3750 95CC1076QQ222 J 2200p VA3 Ceramic AE
(LC-32/37G4U)
C3751 95CC10A9RQ102 J 1000p 1kV Ceramic AE
C3752 95CC30A0DQ331 J 330(ZL) 35V Electrolytic AH
C3753 95CC30A0DQ331 J 330(ZL) 35V Electrolytic AH
C3754 95CC30A0DQ331 J 330(ZL) 35V Electrolytic AH
C3756 95CC10Q0CQ105 J 1 25V Ceramic AE
C3757 95CC30A0DQ331 J 330(ZL) 35V Electrolytic AH
C3758 95CC10Q0CQ105 J 1 25V Ceramic AE
C4701 95CC3042MQ820 J 82(KMG) 450V Electrolytic AU
C4703 95CC2047MQ224 J 0.22 450V Film AN
C4705 95CC1093AQ472 J 4700p 50V Ceramic AE
C4706 95CC1094EQ222 J 2200p 50V Ceramic AE
C4707 95CC1094EQ101 J 100p 50V Ceramic AC
C4708 95CC1095EQ103 J 0.01 50V Ceramic AC
C4709 95CC1093AQ472 J 4700p 50V Ceramic AE
C4751 95CC10A9RQ102 J 1000p 1kV Ceramic AE
C4752 95CC3135DS102 J 1000(ZL) 35V Electrolytic
C4753 95CC30A0DQ331 J 330(ZL)35V Electrolytic AH
C4754 95CC30A0DQ331 J 330(ZL)35V Electrolytic AH
C4756 95CC10Q0CQ105 J 1 25V Ceramic AE
C4757 95CC30A0DQ331 J 330(ZL) 35V Electrolytic AH
C4758 95CC10Q0CQ105 J 1 25V Ceramic AE
RESISTORS
å R2701 95CR1063BQ564 J 560k 1/2W Resistor AD
R2702 95CR3133AC274 J 270k 1/4W Resistor AC
R2703 95CR3133AC274 J 270k 1/4W Resistor AC
R2704 95CR3133AC274 J 270k 1/4W Resistor AC
R2705 95CR5101ELR22 J 0.22 3W Resistor AM
R2706 95CR5101ELR22 J 0.22 3W Resistor AM
R2708 95CR3131AC100 J 10 1/4W Resistor AB
R2709 95CR3131AC100 J 10 1/4W Resistor AB
R2710 95CR3121TC103 J 10k 1/8W Resistor AB
R2711 95CR3121TC103 J 10k 1/8W Resistor AB
R2713 95CR3136AC224 J 220k 1/4W Resistor AC
R2714 95CR3136AC224 J 220k 1/4W Resistor AC
R2715 95CR3136AC224 J 220k 1/4W Resistor AC
RDENCA058WJZZ (LC-32/37G4U)
RDENCA059WJZZ (LC-32/37G4D)
POWER SUPPLY Unit(Continued)
