Sharp LC-32LB591C

18
LC-32LB591U / LC-32LB591C 32" HD LED 720p Sharp Roku TV
AV (good)
1 Make sure that your TV’s power cord is unplugged and all connected devices are turned off.
2 Connect the incoming cable from the cable wall jack to the cable-in jack on the cable or satellite box.
3 Connect an AV cable (not provided) to the VIDEO jack and L and R (audio) jacks on the left side of your TV and to the AV
and audio out jacks on the cable or satellite box.
4 Plug your TV’s power cord into a power outlet, turn on your TV, then turn on the cable or satellite box.
5 On the Home screen, press or to highlight the AV tile, then press OK.
Notes
Cables are often color-coded to match color-coded jacks.
Note
When you connect the audio using the L and R (audio) jacks, the audio
output is analog.
Cable or
satellite box
AV cable
Left side
of TV
AV cable
connector
AV jack
Audio cable
connectors
Analog
audio jacks
On your TV
Cable
wall jack
