102

LC-32LD164

LC-32LD165

LC-32LD166

REF No. PARTS DESCRIPTION

PRICE

CODE

J9103 095G 90 23 JUMP WIRE - - -

J9104 095G 90 23 JUMP WIRE - - -

J9105 095G 90 23 JUMP WIRE - - -

J9106 095G 90 23 JUMP WIRE - - -

J9107 095G 90 23 JUMP WIRE - - -

J9108 095G 90 23 JUMP WIRE - - -

J9109 095G 90 23 JUMP WIRE - - -

J9110 095G 90 23 JUMP WIRE - - -

J9111 095G 90 23 JUMP WIRE - - -

J9112 095G 90 23 JUMP WIRE - - -

J9113 095G 90 23 JUMP WIRE - - -

J9114 095G 90 23 JUMP WIRE - - -

GND1 009G6005 1 GND TERMINAL -

GND2 009G6005 1 GND TERMINAL -

GND3 009G6005 1 GND TERMINAL -

GND4 009G6005 1 GND TERMINAL -

GND5 009G6005 1 GND TERMINAL -

HS9101 Q90T0236007A0000BF HEAT SINK -

HS9102 Q90T0236004A0000BF HEAT SINK -

NR9901 361G0058309MYW007A NTCR 3 OHM 20% 3.6W SCK15037MTY503 -

NR9902 361G0058309MYW007A NTCR 3 OHM 20% 3.6W SCK15037MTY503 -

RV9901 361G0046621KZW VARISTOR 620V 10% -

RV9902 361G0046621KZW VARISTOR 620V 10% -

SG9903 362G0010501MIT SPARK GAP 500V -20/+30% -

SG9904 362G0010501MIT SPARK GAP 500V -20/+30% -

T9101 380GL32P143N00 X'FMR 330UH 10% 5.0UH ER31 - -

BD9101 393G0050460A04 BRIDGE TS6K80-02 6A 800V KBJ -

CN201 033G8032 5F S HR CONNECTOR -

R201 061G0603153 JY RST CHIPR 15KOHM 1/10W YAGEO -

R203 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA -

R202 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA -

C201 065G060310432K F CAP CHIP 0603 0.1UF K 50V X7R -

LED201 081G 14 24 EL CHIP LED BLUE/DARK RED -

U201 356GS927057 IR RECEIVER IRM-H938M3/TR2 38 KHZ 6V -

CN01 033G8032 4F X WAFER 1.25MM 4P R/A S1315-04RVB-S01-K -

R04 061G08051001FT RST CHIP 1K 1/8W 1% -

R03 061G08051801FY RST CHIP R 1K8 +/-1% 1/8W -

R02 061G08052701FY RST CHIP 2K7 1/8W 1% -

R05 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA -

R06 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA -

R07 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA -

R01 061G08057501FY RST CHIP R 7K5 1/8W +/-1% -

SW04 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01 -

SW01 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01 -

SW02 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01 -

SW07 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01 -

SW03 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01 -

SW06 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01 -

SW05 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01 -

LC-32LD164/165/166

IR BOARD

LC-32LD164/165/166

KEY BOARD
