Sharp LC-32LD165E Service Manual

41
LC-32LD164
LC-32LD165
LC-32LD166
2838 100 05424
TPV
2K14 SHARP EU/EU_2G/UK Family
TYPE
:
BRAND
:
Yolin Chen
170 3
10.1
Introduction
Before you start to upgrade new code, we suggest you setup the environment first.
This chapter lists setup requirements, guides you to setup your environment.
10.2 Connect to ISP Board to upgrade the boot loader.
Use USB cable connecting PC & ISP board and use UART/HDMI cable connecting
ISP board & MTK Board.
► Unzip USB2COM Driver .zip to C:\
I. PL2303_Prolific_DriverInstaller_v1.7.0.exe
II. Double click exe file to install driver.
► Unzip FlashTool .zip to C:\
USB Cable
Use Desktop PC or Notebook
USB Port
ISP Board
(USB to UART/HDMI)
UART
/HDMI
MT5561
Board
