LC-50LD264–LC-50LD265–LC-50LD265RU–LC-50LD266
29
<External input SCART>No picture on the display (7)
↓
Does not the picture of the SCART video signal input to SCART go out?
TERMINAL_UNIT:
↓
MAIN_UNIT:
↓YES
↓YES
Is AV signal sent to pin (20)/ SCT1_AV_IN, pin (15)/ SCT1_R_IN,
pin (11)/ SCT1_G_IN, pin (7) SCT1_B_IN of AV1(CN116) ?
NO
Check the setting of an external input device that connects of
CN151.
Refer to “The picture doesn't appear in all modes.”
Is AV signal sent to pin (V18)/ CVBS0P, (U14)/ Y0P, (U15)/ PB0P,
(W16)/ PR0P, (20)/V of IC U401?
NO
Check the line between IC U401 and CN151.
To Next Page
