LC-32LD164
LC-32LD165
LC-32LD166
Item Parts Code Description
1 750TBV315V2000 PANEL TPT315B5-XVN02 900G XM TPV X
2 P34T1535ADT01T0100 DECO_BEZEL
3 378G0110567YAT SPEAKER
4 X15T875220100000AJ BKT_STAND
5 X15T875320100000AJ BKT_STAND
6 P33T0486ADTJ1T0100 COVER_KEY
7 P34T2099ADT0100 STAND BASE
8 X15T934910100000AJ BKT_CHASIS R
9 X15T934810100000AJ BKT_CHASIS L
10 Q12G6300 25 1 FOOT PAD
11 X52G18010TV21800JY MYLAR
12 705TXESPJ0800X POWER BOARD
13 IRPFDXC2 IR BOARD
CBPFD7PBX6 MAIN BOARD
DSETUG410FM09 Main BOARD WITH TUNER
15 X15T9386101000GMAJ BKT_IO_SIDE
16 X85T805720100000AJ SHIELD_IO
17 P34T1467ADT0KT0100 REAR_COVER
18 Q02G707105000100XL BOLT
19 0M1G1030 8 47 CR3 SCREW(DECO/PANEL)
20 0M1G1730 6120 SCREW(MAIN BOARD,POWER BOARD/PANEL)
21 0M1G1030 8 47 CR3 SCREW(STAND_BKT,DECO/PANEL )
22 0Q1G 940 6 47 CR3 SCREW(STAND_BKT,DECO/PANEL )
23 0Q1GF 140 8120 SCREW(BASE_STAND_BKT/BASE)
24 0M1G174 20225 CR3 SCREW(BASE/STAND_BKT)
25 0M1G1030 8 47 CR3 SCREW(REAR COVER/PANEL,AC SOCKET)
26 0Q1G 940 10 47 CR3 SCREW(REAR COVER/DECO)
27 0M1G 330 8 47 CR3 SCREW(REAR COVER/BACK_IO_HDMI)
28 0Q1G 330 8 47 CR3 SCREW(REAR COVER/BACK_IO)
29 0M1G 130 6 47 CR3 SCREW(REAR COVER/BKT_IO_SIDE)
MODEL:LC-32LD166K
