REF No. PARTS DESCRIPTION *
PRICE
CODE
FB609 071G 59S121 M HIP BEAD 120R/500MA - --
FB701 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB702 071G 56A221 TA IND FXD 0805 EMI 100MHZ 220R R - --
FB703 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB704 071G 56K121 M CHIP BEAD 0805 120R 25% MGLB2012E121T-L - --
FB706 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 - --
C101 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C102 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C103 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C104 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C1043 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C105 065G0402105A5KT CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --
C106 065G040215232KY CAP CHIP 0402 1.5NF 50V X7R - --
C107 065G040247312KA CAP 0402 47NF 10% 16V X7R - --
C108 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C109 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C110 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C111 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C112 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C113 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C114 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C115 065G060322515K A 0603 2.2UF K 16V X5R - --
C116 065G060322515K A 0603 2.2UF K 16V X5R - --
C117 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C118 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C119 065G040247312KA CAP 0402 47NF 10% 16V X7R - --
C120 065G040233131JA MLCC 0402 330PF 50V NP0 +-5% - --
C121 065G040247031JY CAP 0402 47PF 5% 50V NP0 - --
C123 065G040247031JY CAP 0402 47PF 5% 50V NP0 - --
C124 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C125 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C126 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C127 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C128 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C129 065G040210031JY CAP 0402 10PF 5% 50V NP0 - --
C130 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C131 065G040247131JA CAP CHIP 0402 470PF J 50V NPO - --
C132 065G060322515K A 0603 2.2UF K 16V X5R - --
C134 065G060322515K A 0603 2.2UF K 16V X5R - --
C135 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C136 065G040210232KF CAP 0402 1NF 10% 50V X7R - --
C137 065G040247131JA CAP CHIP 0402 470PF J 50V NPO - --
C139 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C141 067G305M1013CV EC 100UF 20% 16V 6.3*7 - --
C142 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C143 065G040247312KA CAP 0402 47NF 10% 16V X7R - --
C144 065G040247312KA CAP 0402 47NF 10% 16V X7R - --
C148 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C149 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C154 065G040222031JA CAP 0402 22PF J 50V NPO - --
C155 065G040222031JA CAP 0402 22PF J 50V NPO - --
C169 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C170 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C171 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C172 065G0805106A5K A CAP 0805 10UF 10% 10V X5R - --
C173 065G0805106A5K A CAP 0805 10UF 10% 10V X5R - --
C174 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C177 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C186 065G0805106A5K A CAP 0805 10UF 10% 10V X5R - --
C190 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C191 065G040222031JA CAP 0402 22PF J 50V NPO - --
C192 065G040222031JA CAP 0402 22PF J 50V NPO - --
C402 065G0603475A5K A CAP 0603 4.7UF 10% 10V X5R CL10A475KP8NN - --
C403 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C404 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C405 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
CAPACITORS
REF No. PARTS DESCRIPTION *
PRICE
CODE
C406 065G040215031JF CAP 0402 15PF J 50V NPO - --
C407 065G040215031JF CAP 0402 15PF J 50V NPO - --
C408 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C409 367G315M1013AV EC 100UF 20% --16V ---- -- --ERF1CM101 - --
C410 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C411 065G060347412K F CAP 0603 470NF 10% 16V X7R - --
C412 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C414 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C415 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C416 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C418 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C419 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C426 065G080522605M T CAP 0805 22UF 20% 6.3V X5R JMK212 BJ226 - --
C427 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C428 065G060322515K A 0603 2.2UF K 16V X5R - --
C430 065G060310605MA MLCC 0603 10UF 6.3V X5R +-20% - --
C432 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C433 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C434 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C435 065G0402105A5KT CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --
C436 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C437 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C438 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C440 065G0603475A5K A CAP 0603 4.7UF 10% 10V X5R CL10A475KP8NN - --
C441 065G0402105A5KY CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --
C443 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C444 065G060310512KA CAP 0603 1UF 10% 16V X7R - --
C446 065G0402105A5KY CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --
C447 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C448 065G040210332KY CAP CHIP 0402 10N 50V X7R +/-10% - --
C449 367G315M1013AV EC 100UF 20% --16V ---- -- --ERF1CM101 - --
C450 065G060310605MA MLCC 0603 10UF 6.3V X5R +-20% - --
C451 065G060310605MA MLCC 0603 10UF 6.3V X5R +-20% - --
C452 065G0402105A5KY CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --
C453 065G0402105A5KT CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --
C454 065G0603475A5K A CAP 0603 4.7UF 10% 10V X5R CL10A475KP8NN - --
C456 065G060310605M A MLCC 0603 10UF 6.3V X5R +-20% - --
C457 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C458 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C459 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C460 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C461 065G060310605M A MLCC 0603 10UF 6.3V X5R +-20% - --
C463 065G060310605M A MLCC 0603 10UF 6.3V X5R +-20% - --
C464 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C501 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C502 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C503 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C504 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C511 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C601 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C606 065G040212131JF CAP 0402 120PF 5% 50V NP0 - --
C607 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C608 065G0402105A5KY CAP 0402 1UF 10% 10V X5R LMK105 BJ105KV - --
C609 067G311F3316RT EC 330UF 20% 35V 10*10.5 - --
C610 065G060310605MA MLCC 0603 10UF 6.3V X5R +-20% - --
C611 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C612 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C613 065G040210412KY CAP 0402 100NF 10% 16V X7R - --
C614 065G060310605M A MLCC 0603 10UF 6.3V X5R +-20% - --
C615 065G060310605M A MLCC 0603 10UF 6.3V X5R +-20% - --
C616 065G060310432KY CAP 0603 100NF 10% 50V X7R - --
C617 065G060310432KY CAP 0603 100NF 10% 50V X7R - --
C618 065G040233131JA MLCC 0402 330PF 50V NP0 +-5% - --
C619 065G060310522KA CAP 0603 1UF 10% 25V X7R CL10B105KA8NNN - --
C621 065G060310522KA CAP 0603 1UF 10% 25V X7R CL10B105KA8NNN - --
C622 065G040233131JA MLCC 0402 330PF 50V NP0 +-5% - --
C623 065G060333332K A CAP CHIP 0603 33NF K 50V X7R - --
