Sharp LC-32LE150M Service Manual

LC-32LE150M
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
S 0106 QSW-KA037WJZZY AC V Switch
S 0107 QSW-KA037WJZZY AC V Switch
SC 1501 QSOCZA347WJQZY AE V Socket
TH 3301 RH-HXA057WJQZY AA V Thermistor
TU 1101 RTUNQA073WJQZ AR V Tuner
X 3301 RCRSCA239WJQZY AD V Crystal
[4] POWER UNIT
C 7001 RC-FZA560WJZZ AA V Capacitor
C 7002 VCKYCY1HB104KY AB V Capacitor 100000p 50V Ceramic
C 7003 VCCCCY1HH220JY AA V Capacitor 22p 50V Ceramic
C 7004 RC-FZA560WJZZ AA V Capacitor
C 7005 VCCCCY1HH331JY AA V Capacitor 330p 50V Ceramic
C 7006 VCCCCY1HH220JY AA V Capacitor 22p 50V Ceramic
C 7007 RC-EZB174WJLA AA V Capacitor
C 7008 RC-EZB326WJZZ+ AA V Capacitor
C 7009 RC-FZA564WJZZ AA V Capacitor
C 7012 RC-KZB009WJZZ AA V Capacitor
C 7101 VCKYPA2HB101K+ AB V Capacitor 100p 500V Ceramic
C 7103 VCCSPA2HL220K+ AB V Capacitor 22p 500V Ceramic
C 7105 RC-EZB384WJZZ+ AA V Capacitor
C 7106 RC-EZA172WJZZ+ AA V Capacitor
C 7107 RC-EZA172WJZZ+ AA V Capacitor
C 7108 VCKYCY1EB103KY AA V Capacitor 22p 25V Ceramic
C 7111 RC-KZA994WJZZ+ AA V Capacitor
C 7112 RC-KZA994WJZZ+ AA V Capacitor
C 7113 VCCCCY1HH331JY AA V Capacitor 330p 50V Ceramic
C 7114 VCKYCY1HB104KY AA V Capacitor 100000p 50V Ceramic
C 7115 VCKYCY1HB104KY AA V Capacitor 100000p 50V Ceramic
C 7801 VCCCCY1HH101JY AA V Capacitor 100p 50V Ceramic
C 7802 VCKYCY1HB473KY AA V Capacitor 47000p 50V Ceramic
C 7803 VCKYCY1HB104KY AA V Capacitor 100000p 50V Ceramic
C 7804 VCKYCY1HB104KY AA V Capacitor 100000p 50V Ceramic
C 7805 RC-EZB989WJZZ+ AA V Capacitor
C 7807 VCKYCY1HB104KY AA V Capacitor 100000p 50V Ceramic
C 7808 VCKYCY1HB103KY AA V Capacitor 10000p 50V Ceramic
C 7809 VCKYCY1HB104KY AA V Capacitor 100000p 50V Ceramic
C 7810 VCCCCY1HH101JY AA V Capacitor 100p 50V Ceramic
C 7811 VCKYCY1HB102KY AA V Capacitor 1000p 50V Ceramic
C 7817 RC-KZA216WJZZY AB V Capacitor
D 7001 RH-DXA198WJZZY AB V Diode
D 7002 RH-DXA198WJZZY AB V Diode
D 7003 RH-DXA198WJZZY AB V Diode
D 7004 RH-DXA198WJZZY AB V Diode
D 7005 RH-DXA095WJZZY AA V Diode
D 7006 VHEZJ16B+++1EY AA V Diode
D 7007 VHDBAV21///-1Y AA V Diode
D 7009 VHDBAV21///-1Y AA V Diode
D 7011 RH-DX0321CEZZY AA V Diode
D 7012 RH-FXA014WJZZ AA V Diode
D 7101 RH-DX0229CEZZ AA V Diode
D 7104 VHEZJ5R6B++1EY AA V Diode
D 7801 VHDSR560///-1 AA V Diode
F 7001 QFS-C3225CEZZ AC V Fuse
IC 7001 VHINCP1251B-1Y AG V IC
IC 7101 VHIKIA431A+-1+ AD V IC-KIA431A-AT/P
IC 7801 VHIMP24830+-1Y AL V IC-MP24830HS-LF-Z
L 7001 RCILFA388WJQZ AD V Coil
L 7801 RCILPB498WJQZ+ AD V Coil
P 7001 QPLGN0270GEZZ AA V -
P 7101 QPLGNB200WJZZ AA V -
P 7801 QPLGNB195WJZZ AA V -
Q 7001 VSKTA1535T+-1Y AA V Transistor KTA1535T-RTK/P
Q 7102 VSISA1530AC-1Y AA V Transistor ISA1530AC-T112V-1R
Q 7103 VS2SC3928AR-1Y AB V Transistor 2SC3928A-T112V-1R
Q 7801 VSMDD4N20//-1Y AA V Transistor MDD4N20YRH
Q 7802 VSMDD1951//-1Y AA V Transistor MDD1951RH
Q 7803 VS2SC3928AR-1Y AA V Transistor 2SC3928A-T112V-1R
Q 7804 VSISA1530AC-1Y AA V Transistor ISA1530AC-T112V-1R
Q 7806 VS2SC3928AR-1Y AA V Transistor 2SC3928A-T112V-1R
Q 7807 VSISA1530AC-1Y AA V Transistor ISA1530AC-T112V-1R
Q 7808 VS2SC3928AR-1Y AA V Transistor 2SC3928A-T112V-1R
Q 7809 VSISA1530AC-1Y AA V Transistor ISA1530AC-T112V-1R
R 7001 RR-HZ0041CEZZY AA V Fuse resistor
R 7002 VRS-CY1JF152JY AA V Resistor 15.2k 1/16w Metal Oxide
R 7003 VRS-TV1JD224JY AA V Resistor 220k Metal Oxide
R 7004 VRS-CY1JF474JY AA V Resistor 470k 1/16w Metal Oxide
R 7005 VRS-TV1JD224JY AA V Resistor 220k Metal Oxide
R 7006 VRD-RA2BE224JY AA V Resistor 220k 1/8w Carbon
R 7007 VRS-TV1JD221JY AA V Resistor 220 Metal Oxide
R 7008 VRD-RA2BE102JY AA V Resistor 1k 1/8w Carbon
R 7009 VRS-TV1JD220JY AA V Resistor 22 Metal Oxide
R 7011 VRS-RG3DB223J+ AA V Resistor 22k 2w Metal Oxide
R 7012 VRS-CY1JF223JY AA V Resistor 22k 1/16w Metal Oxide
R 7013 VRS-CY1JF000JY AA V Resistor 0 1/16w Metal Oxide
[3] DKEYMG310FM01 / DKEYMG310FM06 (MAIN Unit)
