Sharp LC-32LE150M Service Manual

LC-32LE150M
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
R 7014 VRN-RL3DBR68J+ AA V Resistor 68 2w Metal Oxide
R 7015 VRN-RL3DBR47J+ AA V Resistor 47 2w Metal Oxide
R 7016 RR-HZ0014GEZZY AA V Fuse resistor
R 7017 VRD-RA2BE393JY AA V Resistor 39k 1/8w Carbon
R 7018 VRD-RA2BE470JY AA V Resistor 47 1/8w Carbon
R 7101 VRS-CY1JF182JY AA V Resistor 1.8k 1/16w Metal Oxide
R 7102 VRS-CY1JF152JY AA V Resistor 15.2k 1/16w Metal Oxide
R 7104 VRS-CY1JF822FY AA V Resistor 8.2k 1/16w Metal Oxide
R 7105 VRS-CY1JF682FY AA V Resistor 6.8k 1/16w Metal Oxide
R 7106 VRS-CY1JF392FY AA V Resistor 3.9k 1/16w Metal Oxide
R 7107 VRS-CY1JF154FY AA V Resistor 150k 1/16w Metal Oxide
R 7108 VRS-CY1JF223JY AA V Resistor 22k 1/16w Metal Oxide
R 7109 VRD-RM2HD100JY AA V Resistor 10 1/2w Carbon
R 7112 VRS-RG3AB682J+ AA V Resistor 6.8k 1w Metal Oxide
R 7113 VRS-RG3AB682J+ AA V Resistor 6.8k 1w Metal Oxide
R 7114 VRS-CY1JF470JY AA V Resistor 47 1/16w Metal Oxide
R 7115 VRS-CY1JF470JY AA V Resistor 47 1/16w Metal Oxide
R 7116 VRS-RG3AB682J+ AA V Resistor 6.8k 1w Metal Oxide
R 7117 VRS-CY1JF122JY AA V Resistor 1.2k 1/16w Metal Oxide
R 7118 VRS-CY1JF823JY AA V Resistor 82k 1/16w Metal Oxide
R 7119 VRS-CY1JF123JY AA V Resistor 12k 1/16w Metal Oxide
R 7120 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7121 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7124 VRS-CY1JF682JY AA V Resistor 6.8k 1/16w Metal Oxide
R 7801 VRS-CY1JF104JY AA V Resistor 100k 1/16w Metal Oxide
R 7802 VRS-CY1JF822FY AA V Resistor 8.2k 1/16w Metal Oxide
R 7803 VRS-CY1JF000JY AA V Resistor 0 1/16w Metal Oxide
R 7804 VRS-CY1JF101JY AA V Resistor 100 1/16w Metal Oxide
R 7805 VRS-TQ2EF1R5FY AA V Resistor 1.5 1/4w Metal Oxide
R 7806 VRS-TQ2EF1R5FY AA V Resistor 1.5 1/4w Metal Oxide
R 7807 VRS-TQ2EF4R7FY AA V Resistor 1.5 1/4w Metal Oxide
R 7808 VRS-CY1JF101JY AA V Resistor 100 1/16w Metal Oxide
R 7809 RR-SZA252WJQZY AA V Fuse resistor
R 7810 VRS-CY1JF680JY AA V Resistor 68 1/16w Metal Oxide
R 7811 VRS-CY1JF304FY AA V Resistor 300k 1/16w Metal Oxide
R 7812 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7813 VRS-CY1JF104JY AA V Resistor 100k 1/16w Metal Oxide
R 7814 VRS-CY1JF332JY AA V Resistor 3.3k 1/16w Metal Oxide
R 7815 VRS-CY1JF122JY AA V Resistor 1.2k 1/16w Metal Oxide
R 7820 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7821 VRS-CY1JF104JY AA V Resistor 100k 1/16w Metal Oxide
R 7822 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7823 VRS-CY1JF104JY AA V Resistor 100k 1/16w Metal Oxide
R 7824 VRS-CY1JF102JY AA V Resistor 1k 1/16w Metal Oxide
R 7827 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7828 VRS-CY1JF104JY AA V Resistor 100k 1/16w Metal Oxide
R 7829 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7830 VRS-CY1JF273JY AA V Resistor 27k 1/16w Metal Oxide
R 7832 VRS-CY1JF103FY AA V Resistor 10k 1/16w Metal Oxide
R 7833 VRS-CY1JF153FY AA V Resistor 15k 1/16w Metal Oxide
R 7835 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7836 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7841 VRS-CY1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 7844 VRS-CY1JF393FY AA V Resistor 39k 1/16w Metal Oxide
T 7001 RTRNWA432WJPZ AN V Transformer
TH 7001 RH-HXA049WJZZ AD V Thermistor
VA 7001 RH-VXA182WJN1 AC V Varistor
[5] LED /IR UNIT ( DUNTKG238FM02)
C 0157 RC-KZA237WJZZY AB V Capacitor
C 0158 RC-KZA237WJZZY AB V Capacitor
D 0152 RH-PXA193WJQZY AB V Diode
D 0153 RH-PXA194WJQZY AB V Diode
P 0151 QPLGNB150WJZZY AA V -
Q 0152 VS2SC3928AR-1Y AB V Transistor 2SC3928A-T112V-1R
Q 0153 VS2SC3928AR-1Y AB V Transistor 2SC3928A-T112V-1R
R 0151 VRS-CZ1JF101JY AA V Resistor 100 1/16w Metal Oxide
R 0152 VRS-CZ1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 0154 VRS-CZ1JF103JY AA V Resistor 10k 1/16w Metal Oxide
R 0158 VRS-CZ1JF151JY AA V Resistor 150 1/16w Metal Oxide
R 0159 VRS-CZ1JF102JY AA V Resistor 1k 1/16w Metal Oxide
R 0159 VRS-CZ1JF102JY AA V Resistor 1k 1/16w Metal Oxide
RMC0151 RRMCUA088WJZZ AE V IR Receiver HM238R-W4
[4] POWER UNIT
