Sharp LC-32LE260M Service Manual

LC-32LE260M
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
1 DKEYMG492FM01 V MAIN UNIT (for ASIA)
1 DKEYMG492FM02 V MAIN UNIT (for SPC)
1 DUNTKG409FM01 V POWER UNIT
1 DUNTKG463FM01 AZ V LED/IR Unit
[2] LCD PANEL
1 R1LK315T3HB60W CE V 32" PANEL Hiraki
1 RUNTKB283WJZZ AZ V LED BAR (A)
1 RUNTKB284WJZZ AZ V LED BAR (B)
1 CLCDTA382WE01 V PANEL ASSEMBLY
[3] MAIN Unit: DUNTKG492FM01/02
P1701 QPLGNB092WJZZY V SP Socket
P3802 QPLGNB101WJZZY V PD Socket
P101 QPLGNB150WJZZY V RA Socket
SC3801 QSOCNB144WJQZY V LVDS Socket
SC3802 QSOCZA321WJQZY V HDMI Socket
SC3803 QSOCZA321WJQZY V HDMI Socket
S101 QSW-KA037WJZZY V Switch
S102 QSW-KA050WJZZY V Switch
FB3309 RBLN-0254TAZZY V Chip Ferrite Bead
FB1101 RBLN-A191WJZZY V Chip Ferrite Bead
FB3302 RBLN-A192WJZZY V Chip Ferrite Bead
FB3310 RBLN-A192WJZZY V Chip Ferrite Bead
C1112 RC-KZA510WJPZY V Chip Capacitor
C1115 RC-KZA510WJPZY V Chip Capacitor
C1738 RC-KZA510WJPZY V Chip Capacitor
C3313 RC-KZA510WJPZY V Chip Capacitor
C3328 RC-KZA510WJPZY V Chip Capacitor
C3802 RC-KZA621WJQZY V Chip Capacitor
C501 RC-KZA691WJZZY V Chip Capacitor
C504 RC-KZA691WJZZY V Chip Capacitor
C507 RC-KZA691WJZZY V Chip Capacitor
C510 RC-KZA691WJZZY V Chip Capacitor
C3801 RC-KZA838WJQZY V Chip Capacitor
C9607 RC-KZA838WJQZY V Chip Capacitor
C9614 RC-KZA838WJQZY V Chip Capacitor
C9627 RC-KZA838WJQZY V Chip Capacitor
L9601 RCILPB014WJQZY V Coil
L9602 RCILPB014WJQZY V Coil
L1701 RCILPB489WJQZY V Coil
L1702 RCILPB489WJQZY V Coil
L1703 RCILPB489WJQZY V Coil
L1704 RCILPB489WJQZY V Coil
X3301 RCRSCA239WJQZY V Crystal
TH3301 RH-HXA057WJQZY V Thermistor
IC3301 RH-IXD632WJQZQ V Main IC
C3345 VCCCCZ1HH120JY V Chip Capacitor
C3346 VCCCCZ1HH120JY V Chip Capacitor
C1105 VCCCCZ1HH220JY V Chip Capacitor
C1701 VCEASY1EN107MY V Chip Capacitor
C1731 VCEASY1EN107MY V Chip Capacitor
C1732 VCKYCY1AB224KY V Chip Capacitor
C1736 VCKYCY1AB224KY V Chip Capacitor
C1737 VCKYCZ1AB104KY V Chip Capacitor
C3310 VCKYCZ1AB104KY V Chip Capacitor
C3315 VCKYCZ1AB104KY V Chip Capacitor
C3317 VCKYCZ1AB104KY V Chip Capacitor
C3318 VCKYCZ1AB104KY V Chip Capacitor
C1740 VCKYCZ1AB105KY V Chip Capacitor
C1742 VCKYCZ1AB105KY V Chip Capacitor
C3321 VCKYCZ1AB105KY V Chip Capacitor
C3305 VCKYCZ1AB473KY V Chip Capacitor
C3308 VCKYCZ1AB473KY V Chip Capacitor
C3316 VCKYCZ1AB473KY V Chip Capacitor
C3319 VCKYCZ1AB473KY V Chip Capacitor
C3329 VCKYCZ1AB473KY V Chip Capacitor
C3334 VCKYCZ1AB473KY V Chip Capacitor
C3309 VCKYCZ1CB103KY V Chip Capacitor
C3303 VCKYCZ1CB104KY V Chip Capacitor
C3307 VCKYCZ1CB104KY V Chip Capacitor
C3311 VCKYCZ1CB104KY V Chip Capacitor
C3322 VCKYCZ1CB104KY V Chip Capacitor
C3331 VCKYCZ1CB104KY V Chip Capacitor
C7819 VCKYCZ1CB104KY V Chip Capacitor
C3301 VCKYCZ1EB103KY V Chip Capacitor
C3302 VCKYCZ1EB103KY V Chip Capacitor
C9608 VCKYCZ1EB104KY V Chip Capacitor
C9615 VCKYCZ1EB104KY V Chip Capacitor
C1739 VCKYCZ1HB102KY V Chip Capacitor
C1741 VCKYCZ1HB102KY V Chip Capacitor
C1744 VCKYCZ1HB102KY V Chip Capacitor
C3312 VCKYCZ1HB102KY V Chip Capacitor
C3339 VCKYCZ1HB102KY V Chip Capacitor
C3340 VCKYCZ1HB102KY V Chip Capacitor
