Sharp LC-32LE260M Service Manual

PARTS GUIDE
No. S94M55LC-32LE260M
LED BACKLIGHT TV
MODEL:
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-32LE260M
LC-32LE260M
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL
[3] MAIN Unit: DUNTKG492FM01/02
[4] LED/IR Unit DUNTKG463FM01
[5] POWER Unit: DUNTKG409FM01
[6] CABINET AND MECHNICAL
PARTS
[7] LCD PANEL
[8] SUPPLIED ACCESSORIES
[9] PACKING PARTS ( NOT REPLACE-
MENT )
[10] EXPLODE VIEW
