LC-32/40/46/52LE700UN
27
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[12] LCD PANEL MODULE (LC-46LE700UN)
1 DLCUCA003FM01 FA N X 46" FHD LCD Panel Module Unit
1-1 PRDARA793WJZZ BK N X Back Light Chassis
1-2 LHLDWA284WJKZ AB N X Bush Base
1-3 RUNTK4225TPZA CS N X LCD Control Unit
1-4 XHPS730P06WS0 AA J Screw, x6
1-5 QCNW-H089WJQZ AG N X Connecting Cord, x2
1-6 RCORFA061WJZZ AG J Ferrite Core, x2
1-7 QCNW-J647WJQZ AU N X Wire Harness
1-8 CHLDWA285WJ01 AC N X Bush Cap Unit
1-9 LHLDWA281WJKZ AC N X Wire Holder, x3
1-10 RUNTKA595WJ01 AX N X LED5 PWB1 Unit, x6
1-11 RUNTKA595WJ02 AX N X LED5 PWB2 Unit, x5
1-12 RUNTKA596WJ01 AY N X LED6 PWB1 Unit, x6
1-13 RUNTKA596WJ02 AY N X LED6 PWB2 Unit, x5
1-14 RUNTKA598WJ01 BA N X LED8 PWB1 Unit, x6
1-15 RUNTKA598WJ02 BA N X LED8 PWB2 Unit, x5
1-16 QCNCWA958WJZZ AD N X Terminator, x11
1-17 LHLDZB497WJKZ AB N X Push Rivet, x98
1-18 PMiR-A256WJZZ AY N X Reflector Sheet
1-19 LHLDZB496WJKZ AB N X Support Pin, x11
1-20 PCOVUA186WJZZ BC N X Diffusion Plate
1-21 PSHEPA966WJZZ AY N X Lens Sheet, x2
1-22 CHLDZB509WJ01 AS N X Panel Chassis Ass'y (Top)
1-23 CHLDZB510WJ01 AS N X Panel Chassis Ass'y (Bottom)
1-24 CHLDZB511WJ01 AM N X Panel Chassis Ass'y (L)
1-25 CHLDZB512WJ01 AM N X Panel Chassis Ass'y (R)
1-26 R1LK460D3FZL0Z DZ N X 46" LCD Panel Unit
1-27 LHLDZ3785TPZZ AC J Clip, x4
1-28 CANGKC333WJ01 AP N X Bezel Ass'y (Top)
1-29 CANGKC334WJ01 AP N X Bezel Ass'y (Bottom)
1-30 CANGKC335WJ01 AN N X Bezel Ass'y (L)
1-31 CANGKC336WJ01 AN N X Bezel Ass'y (R)
1-32 LX-EZA028WJF9 AB J Screw, x16
1-33 LX-HZA039WJF7 AB J
Screw, x10
1-34 TLABN2229TPZZ AA J bar Code Label
