Sharp LC-32LE700UN Service Manual

LC-32/40/46/52LE700UN
5 – 10
36 1 LCD TEST PATTERN
2 LCD AGI TEST PATTERN
3 LCD EVA TEST PATTERN
4 YEL TEST PATTERN
5 TV TEST PATTERN 1
6 TV TEST PATTERN 2
37 1 REGISTER ADDRESS LOWER
2 READ/WRITE
3 SLAVE ADDRESS
4 REGISTER ADDRESS UPPER
5 WRITE DATA UPPER
6 WRITE DATA LOWER
7 READ DATA UPPER
8 READ DATA LOWER
38 1 KEY LOCK(1217)
2 KOUTEI AREA ALL CLEAR
3 A MODE AREA CLEAR
4 BACKUP AREA CLEAR
5 B MODE AREA CLEAR
6 EXECUTION
39 1 ERROR STANDBY CAUSE1
2 ERROR STANDBY CAUSE2
3 ERROR STANDBY CAUSE3
4 ERROR STANDBY CAUSE4
5 ERROR STANDBY CAUSE5
6 ERROR STANDBY CAUSE
RESET
40 1 EEP SAVE Writing setting values to EEPROM
2 EEP RECOVER Reading setting values from EEPROM
3MODL NAME
4 PANEL SIZE
5 SETTING FOR ADJ
6 PANEL LIMIT
7 PANEL RANGE LIMIT
8 SHORT CHECK MODE
9 SHORT CHECK CURRENT
10 CURRENT SW
*1 Details of P1.9 (NORMAL STANDBY CAUSE)
2 No operation off in the cause of “no operation off”
3 No signal off in the cause of “no signal off”
4 PC power management mode 1 in the cause of “Standby mode MODE1”
5 PC power management mode 2 in the cause of “Standby mode MODE2”
6 Off timer in the cause of “SLEEP timer”
8 Command from RS232C in the cause of command by RS-232C
Page Line Item Description Remarks (adjustment detail, etc.)

Sharp LC-32LE700UN Specifications

General

Brand	Sharp
Model	LC-32LE700UN
Category	TV
Language	English
