LC-32LE705E
Service Manual
OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE
LC-32/40/46LE705E/S, LU705E/S, LX705E, 52LE705E/S has been issued to cover the modifications of some parts in reference to redesigned LCD
panel module of Model LC-32/40/46/52LE700E/S. In this Service Manual, the modifications from Model LC-32/40/46/52LE700E/S (No.
S89B4LC32L700) are focused on. For what is left out herein, please refer back to the Service Manual of the previous model LC-32/40/46/52LE700E/
S (No. S89B4LC32L700).
LIST OF CHANGED PARTS (LC-32LE705E/S, LU705E/S, LX705E)
NOTE: If it is necessary to replace IC8401 and IC3302, replace the main unit.
Ref No. Description LC-32LE/LU/LX700E/S
(No. S89B4LC32L700)
LC-32LE/LU705E/S/LX705E
(No. SX9D1LC32L705 )
Interchangeability Note
PRINTED WIRING BOARD ASSEMBLIES
MAIN Unit DUNTKF306FM01 DKEYDF306FM10 D Changed
KEY Unit DUNTKE266FM18 ← — No change
R/C, LED Unit DUNTKF308FM02 ← — No change
ICON Unit DUNTKF314FM02 ← — No change
POWER Unit RUNTKA619WJQZ ← — No change
LCD Control Unit RUNTK4225TPZU ← — No change
LED5-PWB1 Unit RUNTKA655WJ01 ← — No change
LED5-PWB2 Unit RUNTKA655WJ02 ← — No change
LED8-PWB1 Unit RUNTKA658WJ01 ← — No change
LED8-PWB2 Unit RUNTKA658WJ02 ← — No change
LCD PANEL
32" LCD Panel Module Unit DLCUCA001FM03 ← — No change
MAIN Unit
IC2002 IC RH-iXC786WJN5Q RH-iXC786WJNAQ D Changed
IC3302 IC RH-iXC773WJQZQ RH-iXC951WJQZQ D Changed
CABINET AND MECHANICAL PARTS
Please refer to a Parts list
LCD MODULE Assembly
Please refer to a Parts list
SUPPLIED ACCESSORIES
Please refer to a Parts list
PACKING PARTS (NOT REPLACEMENT ITEM)
Please refer to a Parts list
Interchangeability
Completely interchangeableA:
=
NEWOLD
Interchangeable from
OLD to NEW
B:
NEWOLD
Interchangeable from
NEW to OLD
C:
NEW OLD
Not interchangeableD:
X
OLDNEW
