LC-32/40/46LE705E/S, LU705E/S, LX705E, LC-52LE705E/S
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DKEYDF306FM10 CD N P MAIN Unit (DUNTKF306FM10)
N DUNTKE266FM18 AR P KEY Unit
N DUNTKF308FM02 AL P R/C, LED Unit
N DUNTKF314FM02 AL P ICON Unit
!
N RUNTKA619WJQZ BS P POWER Unit (for 32 inch model)
!
N RUNTKA642WJQZ P POWER Unit (for 40 inch model)
!
N RUNTKA643WJQZ P POWER Unit (for 46/52 inch model)
N RUNTK4225TPZU BR N P LCD Control Unit
N RUNTKA655WJ01 AU N J LED5-PWB1 Unit (for 32/40/46 inch model)
N RUNTKA655WJ02 AU N J LED5-PWB2 Unit (for 32/40/46 inch model)
N RUNTKA656WJ01 AW N J LED6-PWB1 Unit (for 40/46/52 inch model)
N RUNTKA656WJ02 AW N J LED6-PWB2 Unit (for 40/46/52 inch model)
N RUNTKA658WJ01 AX N J LED8-PWB1 Unit (for 32/46/52 inch model)
N RUNTKA658WJ02 AX N J LED8-PWB2 Unit (for 32/46/52 inch model)
[2] LCD PANEL
N DLCUCA001FM03 DL P 32"LCD Panel Module Unit (for 32 inch model)
N DLCUCA002FM07 DS N P 40"LCD Panel Module Unit (for 40 inch model)
N DLCUCA003FM07 DR N P 46"LCD Panel Module Unit (for 46 inch model)
N DLCUCA004FM07 DU N P 52"LCD Panel Module Unit (for 52 inch model)
[3] DKEYDF306FM10 (MAIN Unit)
IC2002 RH-iXC786WJNAQ J IC R5F364A6NFB (Monitor Micon)
IC8401 Not Available - - IC K9F1208U0C-PCB0 *PWB replacement item
IC3302 Not Available - - IC MT5391DWCJ (MAIN CPU) *PWB replacement item
