Sharp LC-32X20E Service Manual

LC-32X20E/S/RU, LC-37X20E/S/RU
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKE237FM02 N R MAIN Unit
N DUNTKE238FM01 N R TERMINAL Unit
N DUNTKE264FM01 AS N R R/C, LED Unit
N DUNTKE266FM01 AR N R KEY Unit
N DUNTKE306FM01 N R MINI AV Unit
N RDENCA230WJQZ R Power Unit
[2] LCD PANEL AND TUNER (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT
NOT INDEPENDENTLY.)
N R1LK315D3LZ20Y N J 32" LCD Panel Module
N R1LK370D3LZ60Y N J 37" LCD Panel Module
!
TU7501 RTUDAA015WJQZ N P Tuner
[3] DUNTKE237FM02 (MAIN Unit)
C1112 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1117 VCCCCZ1HH3R0CY AA J Capacitor 30p 50V Ceramic
C1118 VCCCCZ1HH3R0CY AA J Capacitor 30p 50V Ceramic
C1119 VCCCCZ1HH3R0CY AA J Capacitor 30p 50V Ceramic
C1120 VCCCCZ1HH390JY AB J Capacitor 39p 50V Ceramic
C1121 VCCCCZ1HH390JY AB J Capacitor 39p 50V Ceramic
C1122 VCCCCZ1HH390JY AB J Capacitor 39p 50V Ceramic
C1123 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1124 VCCCCZ1HH181JY AB J Capacitor 180p 50V Ceramic
C1125 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C1126 VCCCCZ1HH471JY AA J Capacitor 470p 50V Ceramic
C1128 VCAAPE1CJ686MY AE J Capacitor 68 16V Electrolytic
C1129 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1130 VCCCCZ1HH150JY AB J Capacitor 15p 50V Ceramic
C1134 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C1135 VCCCCZ1HH330JY AB J Capacitor 33p 50V Ceramic
C1136 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C1137 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1138 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1139 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C1140 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C1141 VCCCCZ1HH101JY AB J Capacitor 100p 50V Ceramic
C1501 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1502 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1503 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1504 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1505 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1506 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1507 RC-KZA195WJZZY AB J Capacitor 10 10V Ceramic
C1508 RC-KZA195WJZZY AB J Capacitor 10 10V Ceramic
C1509 VCKYCZ1HB221KY AA J Capacitor 220p 50V Ceramic
C1510 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1511 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1512 VCKYTV1CB105KY AC J
Capacitor 1 16V Ceramic
C1513 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1514 VCERML1CN106MY AC J Capacitor 10 16V Electrolytic
C1515 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1516 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1517 RC-KZA195WJZZY AB J Capacitor 10 10V Ceramic
C1518 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1519 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1521 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1522 RC-KZA510WJPZY AB J Capacitor 10 16V Ceramic
C1523 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1524 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1525 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1526 VCKYTV1CB105KY AC J Capacitor 1 16V Ceramic
C1531 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1532 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1534 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1535 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1538 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1540 VCAAPE0JJ227MY AE J Capacitor 220 6.3V Electrolytic
C1543 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1544 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1545 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1546 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1547 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1548 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1551 RC-KZA195WJZZY AB J Capacitor 10 10V Ceramic
C1578 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1579 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1582 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1583 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1586 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1587 VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1589 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1591
VCKYCZ1HB102KY AB J Capacitor 1000p 50V Ceramic
C1592 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
C1596 VCKYCZ1CF104ZY AA J Capacitor 0.1 16V Ceramic
