PARTS GUIDE
No. S19W2LC37A37M
MODEL
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-37A37M
LC-37A37M
LCD COLOR TELEVISION
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD UNIT
[3] DUNTKF064FM02 (POWER UNIT)
[4] DUNTKF072FM01 (INVERTER
UNIT)
[5] CABINET PARTS
[6] LCD PANEL MODULE
[7] SUPPLIED ACCESSORIES
[8] PACKING PARTS (NOT
REPLACEMENT ITEM)
[9] SERVICE JIG (USE FOR
SERVICING)
