LC-32D65E/RU, LC-37D65E/RU
4 – 5
<LC-32DH65E, LC-37DH65E>
The audio signal is not output (2)
No audio signal output from EXT1/EXT2 terminal.(HDMI/DTV(H.264))
Is there a audio output signal in pins(3/L-ch) and (1/R-ch) of
EXT1(SC502)?
YES Check the setting of an external input device that connects with
EXT1.
Is there a audio output signal in pins(3/L-ch) and (1/R-ch) of
EXT2(SC501)?
YES Check the setting of an external input device that connects with
EXT2.
NO
<EXT1>
Is SC-MUTE [pin(67) of IC9101(CPLD)] at H?
YES Check the peripheral circuits of IC9101 and SC-MUTE.
(Q503, Q505, etc.)
<EXT2>
Is SC2-MUTE [pin(65) of IC9101(CPLD)] at H?
YES Check the peripheral circuits of IC9101 and SC2-MUTE.
(Q502, Q504, etc.)
NO
<EXT1>
Is there a audio output signal in pins(39/SC1_OUT_L) and (38/
SC1_OUT_R) of IC503(AV_SW)?
YES Check the line between IC503 and SC502.
<EXT2>
Is there a audio output signal in pins(37/SC2_OUT_L) and (36/
SC2_OUT_R) of IC503(AV_SW)?
YES Check the line between IC503 and SC501.
NO
<EXT1>When the HDMI signal
Is there a audio input signal in pins(60/L1) and (59/R1) of
IC503(AV_SW)?
YES Check IC503 and its peripheral circuits.
<EXT2>When the HDMI signal
Is there a audio input signal in pins(58/L2) and (57/R2) of
IC503(AV_SW)?
When the DTV(H.264) signal
Is there a audio input signal in pins(44/L9) and (43/R9) of
IC503(AV_SW)?
NO
<EXT1>When the HDMI signal
Is there a audio output signal in pins(1/OUTTNL) and (2/OUT-
TNR) of IC1302(DSP)?
YES Check the line between IC1302 and IC503.
<EXT2>When the HDMI signal
Is there a audio output signal in pins(17/OUT2L) and (18/
OUT2R) of IC1302(DSP)?
When the DTV(H.264) signal
Is there a audio input signal in pins(11/AOUT_L) and (10/
AOUT_R) of IC504(AUDIO_DAC)?
YES Check the line between IC504 and IC503.
NO
When the HDMI signal
Is there signal of HDMI_SD0/WS/SCK input to pin (76, 77, 78) of
IC1302?
YES Check IC1302 and its peripheral circuits.
When the DTV(H.264) signal
Is H.264_I2S signal input to pin (13/H.264_I2S_MCLK), (3/
H.264_I2S_SCLK), (6/H.264_I2S_LRCLK) and (10/
H.264_I2S_DATA) of IC1306 (SW.)?
YES Check IC1306, IC504 and its peripheral circuits
NO
When the HDMI signal
Is there signal of HDMI_SD0/WS/SCK output to pin (C10, E10,
D10) of IC8101(DIGITAL AV DECODER & MAIN CPU & VIDEO
PROCESSER)?
No Check IC8101 and its peripheral circuits.
When the DTV(H.264) signal
Is H.264_I2S signal output from pin (D26/H.264_I2S_MCLK),
(E24/H.264_I2S_SCLK), (E26/H.264_I2S_LRCLK) and (A25/
H.264_I2S_DATA) of IC5001 (H.264_DECODER)?
NO Check IC5001 and its peripheral circuits.
