LC-37D90U
5 – 48
2, 4, 5, 7,
8, 10, 11,
13, 54,
56, 57,
59, 60,
62, 63,
65
DQ [0 : 15] I/O Data Input/Output : Data bus.
16, 51 L(U)DQS I/O Data Strobe : Output with read data, input with write data. Edge-aligned with read data, centered in write
data. Used to capture write data. LDQS corresponds to the data on DQ0~D7 ; UDQS corresponds to
the data on DQ8~DQ15.
14, 17,
19, 25,
43, 50,
53
NC --- No Connect : No internal electrical connection is present.
3, 9, 15,
55, 61
VDDQ --- DQ Power Supply : +2.5V ± 0.2V.
6, 12, 52,
58, 64
VSSQ --- DQ Ground.
1, 18, 33 VDD --- Power Supply : +2.5V ± 0.2V (device specific).
34, 48,
66
VSS --- Ground.
49 VREF I SSTL_2 reference voltage.
Pin No. Pin Name I/O Pin Function
To Next Page
