LC-32LD145
LC-39LD145
10. CONNECTORS
10.1. HDMI (CN707,CN708)
10.2. USB(CN37, CN38)
36
Pin Name
Cable color
1
VBUS
Red
2 D-
White (gold*)
3
D+
Green
4 GND
Black
(blue*)
Cable color
Description
Red
5 V
White (gold*)
Data −
Green
Data+
Black
(blue*)
Ground
