Sharp LC-39LD145V Service Manual

99
LC-32LD145
LC-39LD145
REF No. PARTS DESCRIPTION *
PRICE
CODE
C310 30000284 CAP SMD 1NF 50V K X7R (0805) ROHS G --
C312 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C314 30067959 CAP EL 1000UF 16V M 105C 8x20LEFTBENDROH G --
C315 30067959 CAP EL 1000UF 16V M 105C 8x20LEFTBENDROH G --
C316 30067959 CAP EL 1000UF 16V M 105C 8x20LEFTBENDROH G --
C318 30068024 CAP EL 47UF 50V M 105C 105mA 8X7 ROHS G --
C324 30067959 CAP EL 1000UF 16V M 105C 8x20LEFTBENDROH G --
C333 30074886 CAP CER SAFE 330PF 4KV M Y5P TAPED ROHS G --
C339 30074885 CAP CER SAFE 1NF 4KV M Y5U TAPED ROHS G --
C501 30015459 CAP SMD 470NF 25V K X7R (0805) ROHS G --
C503 30068742 CAP SMD 1UF 50V K X7R (1206) ROHS G --
C504 30068742 CAP SMD 1UF 50V K X7R (1206) ROHS G --
C505 30000289 CAP SMD 10NF 50V K X7R (0805) ROHS G --
C507 30000289 CAP SMD 10NF 50V K X7R (0805) ROHS G --
C510 30067121 CAP SMD 2.2UF 16V K X5R (1206) ROHS G --
C511 30000256 CAP SMD 470PF 50V J COG (0805) ROHS G --
C514 30068839 CAP EL 33UF 100V M105C288mA 8X12LEFTROHS G --
C515 30068839 CAP EL 33UF 100V M105C288mA 8X12LEFTROHS G --
R100 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R101 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R102 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
R103 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R104 30039196 RES SMD 1/4W 1M F 1206 ROHS G --
R105 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
R112 30000795 RES SMD 1/8W 75R J 1206 ROHS G --
R113 30060262 RES SMD 1/4W 33R J (1206) ROHS G --
R114 30069236 CAP VAR SAFE 510V K D:14 KINK ROHS G --
R115 30001735 RES SMD 1/8W 0R 1206 ROHS G --
R116 30001735 RES SMD 1/8W 0R 1206 ROHS G --
R209 30000480 RES SMD 1/10W 100K J 0805 ROHS G --
R210 30000517 RES SMD 1/10W 15R J 0805 ROHS G --
R212 30000464 RES SMD 1/10W 100R J 0805 ROHS G --
R217 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R219 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R220 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R225 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R227 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R228 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R229 30066355 RES MG SAFE 1/2W 4.7M J NEW ROHS G --
R230 30000592 RES SMD 1/8W 2.2K J (1206) RoHS G --
R231 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R232 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R233 30064316 RES SMD 1/8W 3.3K F (0805) ROHS G --
R234 30015473 RES SMD 1/10W 150R F(0805) G --
R235 30058193 RES SMD 1/8W 30K F 0805 ROHS G --
R244 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R257 30000480 RES SMD 1/10W 100K J 0805 ROHS G --
R261 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO G --
R272 30001173 RES MO 1W 0.47R J ROHS G --
R277 30001735 RES SMD 1/8W 0R 1206 ROHS G --
R278 30001735 RES SMD 1/8W 0R 1206 ROHS G --
R301 30055432 RES SMD 1/4W 1.5R F (1206)ROHS G --
RESISTORS
REF No. PARTS DESCRIPTION *
PRICE
CODE
R302 30066311 RES SMD 1/4W 2.7R F 1206 ROHS G --
R303 30066311 RES SMD 1/4W 2.7R F 1206 ROHS G --
R304 30066311 RES SMD 1/4W 2.7R F 1206 ROHS G --
R310 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R323 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R324 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R325 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R326 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R330 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R331 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R332 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R333 30060652 RES SMD 1/4W 100K J (1206) RoHS G --
R337 30000455 RES SMD 1/8W 10R J (1206) ROHS G --
R339 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
R343 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R344 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R352 30033730 RES SMD 1/10W 2.2K F 0805 ROHS G --
R353 30000659 RES SMD 1/10W 330R J 0805 ROHS G --
R354 30000529 RES SMD 1/10W 1.5K J 0805 ROHS G --
R355 30007019 RES SMD 1/10W 10K F 0805 ROHS G --
R356 30000668 RES SMD 1/10W 33K J 0805 ROHS G --
R357 30025823 RES SMD 1/10W 15K F 0805 ROHS G --
R358 30000692 RES SMD 1/10W 3.9K J 0805 ROHS G --
R359 30000696 RES SMD 1/10W 39K J 0805 ROHS G --
R360 30020394 FERRIT SMD 330/100MHZ 0.1R M 1.5A 805RO G --
R362 30000592 RES SMD 1/8W 2.2K J (1206) RoHS G --
R364 30000592 RES SMD 1/8W 2.2K J (1206) RoHS G --
R365 30000592 RES SMD 1/8W 2.2K J (1206) RoHS G --
R367 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R369 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R371 30000506 RES SMD 1/10W 120K J 0805 ROHS G --
R374 30000727 RES SMD 1/10W 47K J 0805 ROHS G --
R500 30000480 RES SMD 1/10W 100K J 0805 ROHS G --
R501 30065314 RES SMD 1/10W 200K F 0805 ROHS G --
R502 30007791 RES SMD 1/10W 4.7K F (0805) ROHS G --
R503 30000774 RES SMD 1/10W 680R J 0805 ROHS G --
R504 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R506 30000626 RES SMD 1/10W 270R J 0805 ROHS G --
R507 30007023 RES SMD 1/10W 270K J(0805) ROHS G --
R508 30007791 RES SMD 1/10W 4.7K F (0805) ROHS G --
R509 30000457 RES SMD 1/10W 10R J 0805 ROHS G --
R511 30001734 RES SMD 1/10W 0R 0805 ROHS G --
R514 30000592 RES SMD 1/8W 2.2K J (1206) RoHS G --
R520 30068816 RES SMD 1/4W 0.2R J (1206)ROHS G --
R521 30068816 RES SMD 1/4W 0.2R J (1206)ROHS G --
R522 30068816 RES SMD 1/4W 0.2R J (1206)ROHS G --
R524 30068816 RES SMD 1/4W 0.2R J (1206)ROHS G --
R528 30000787 RES SMD 1/10W 680K J 0805 ROHS G --
R529 30012355 RES SMD 1/10W 6.8K F 0805 RoHS G --
R530 30007021 RES SMD 1/10W 1K F 0805 ROHS G --
MISCELLANEOUS PARTS
