25
LC-40LE732
LC-46LE732
2. Removing of major Parts 46” (Continued)
9. Remove the 8 lock screws and detach the VESA brackets.
10. Remove the 6 lock screws 2 lock screws and detach the STAND bracket.
11. Remove the 2 lock screws and detach the CONTROL BUTTON unit.
9
12
11
10
9
VESA brackets
STAND
bracket
10
11
CONTROL
BUTTON
unit
12
