Sharp LC-40LE732E User Manual

79
LC-40LE732
LC-46LE732
REF No. PARTS DESCRIPTION *
PRICE
CODE
FB 9601 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9602 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9603 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9604 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9605 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9606 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9607 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9608 VRS-TV1JD000JY RES 2125 0 OHM 5% 1/10W SMD P AA
FB 9609 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
FB 9610 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD P AA
FB 9611 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9612 VRS-CY1JF000JY RES 0603 0 OHM 5% 1/10W SMD P AA
FB 9613 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9614 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9615 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9616 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9617 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9618
RBLN A529WJZZY
FERRITE MI0603M121R 10
P
AE
FB 9618 RBLN-A529WJZZY FERRITE MI0603M121R-10 P AE
FB 9701 RBLN-A528WJZZY FERRITA HI0805N600R-10 P AA
L 1101 VPDBNR33JR45NY BOBINA NLV25T-R33J-PF P AB
L 1102 VPDBNR33JR45NY BOBINA NLV25T-R33J-PF P AB
L 1301 RCILPB017WJQZY COIL SWPA6045S330 P AB
L 1302 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 1303 RCILP0303TAZZY COIL SLF10145-221MR65 P AD
L 2601
VRS CA1JF000JY
ARRAY 2 RES 0 OHM 5% 1/16W SMD
P
AE
L 2601 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2602 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2603 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2604 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2605 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2606 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2607 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2608
VRS CA1JF000JY
ARRAY 2 RES 0 OHM 5% 1/16W SMD
P
AE
L
2608
VRS
-
CA1JF000JY
ARRAY
2
RES
0
OHM
5%
1/16W
SMD
P
AE
L 2609 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2610 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2611 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2612 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2613 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2614 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2615
VRS-CA1JF000JY
ARRAY 2 RES 0 OHM 5% 1/16W SMD
P
AE
L
2615
VRS
-
CA1JF000JY
ARRAY
2
RES
0
OHM
5%
1/16W
SMD
P
AE
L 2616 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2617 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2618 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2619 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2620 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2621 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2622
VRS
-
CA1JF000JY
ARRAY 2 RES 0 OHM 5% 1/16W SMD
P
AE
L
2622
VRS
-
CA1JF000JY
ARRAY
2
RES
0
OHM
5%
1/16W
SMD
P
AE
L 2623 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2624 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 2701 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 2702 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 2703 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 2704 RCILPB016WJQZY COIL SWPA6045S220 P AD
L 3301
VRK
-
SB1FF000JY
RES 0 OHM 5% 1/32W SMD
P
AA
L
3301
VRK-SB1FF000JY
RES
0
OHM
5%
1/32W
SMD
P
AA
L 3302 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3303 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3304 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
REF No. PARTS DESCRIPTION *
PRICE
CODE
L 3305 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3306 VRK-SB1FF000JY RES 0 OHM 5% 1/32W SMD P AA
L 3337 VPDBN1R8J1R1NY BOBINA NLV25T-1R8J-PF P AB
L 3338 VPDBN1R8J1R1NY BOBINA NLV25T-1R8J-PF P AB
L 9551 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 9552 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 9553 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 9554 VRS-CA1JF000JY ARRAY 2 RES 0 OHM 5% 1/16W SMD P AE
L 9601 RCILPB014WJQZY COIL SWPA6045S100 P AC
L 9602 RCILPB011WJQZY COIL SWPA6045S2R7 P AB
L 9701 RCILPB014WJQZY COIL SWPA6045S100 P AC
TU 1101 RTUDAA090WJQZ TUNER TDSV-G081D LOW IF DVB-T/T2/C LG P AV
T 1102 RTUDSA029WJQZ DIGITAL DBS TUNER A3BS2S7HZ6702W P AX
C 0501 RC-KZA926WJQZY C CERAM 10uF 6,3V GRM188B30J106ME47D P
C 0502
VCCCCZ1HH331JY
CERAM C 0402 330PF 50V 5%
P
AA
TUNER
CAPACITORS
C 0502 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0503 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0504 VCCCCZ1HH561JY CERAM C 0402 560PF 50V 5% P AA
C 0505 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0506 VCCCCZ1HH561JY CERAM C 0402 560PF 50V 5% P AA
C 0507 VCCCCY1HH101JY CONDENSADOR GRM39CK 101J 50 (1608)SMD P AA
C 0508 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0510 VCCCCZ1HH100DY C CERAM 0402 10PF 50V 0,5% P AA
C 0512 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0513 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0514 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0515 VCKYCZ1HB472KY C CERAM 0402 4,7NF 50V 10% P AA
C 0516 VCKYCZ1AB474KY C CERAM 0402 470NF 10V 10% P AB
C 0517
VCKYCZ1AB474KY
C CERAM 0402 470NF 10V 10%
P
AB
C
0517
VCKYCZ1AB474KY
C
CERAM
0402
470NF
10V
10%
P
AB
C 0537 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 0538 VCCCCZ1HH220JY CERAM C 0402 22PF 50V 5% P AA
C 0539 RC-KZA926WJQZY C CERAM 10uF 6,3V GRM188B30J106ME47D P AA
C 0554 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0555 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0557 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0558
VCCCCZ1HH331JY
CERAM C 0402 330PF 50V 5%
P
AA
C 0558 VCCCCZ1HH331JY CERAM C 0402 330PF 50V 5% P AA
C 0559 VCCCCZ1HH470JY CERAM C 0402 47PF 50V 5% P AA
C 0560 VCCCCZ1HH470JY CERAM C 0402 47PF 50V 5% P AA
C 0561 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0562 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0563 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0566 VCKYCZ1EF104ZY C CERAM 0402 100NF 25V 20% P AD
C 0568 VCEASY1CN107MY C ELEC 100UF 20% 16V MVL16VC100MF61 P AB
C 0572 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0573 RC-KZA237WJZZY C CERAM EMK212BJ106KGFT 10UF 16V 10% P AD
C 0574 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0575 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0576 VCKYCZ1CB473KY C CERAM 0402 47NF 16V 10% P AB
C 0577
VCAAPE0JJ227MY
C ELEC 220UF 20% 6 3V 6SVP100M
P
AH
C
0577
VCAAPE0JJ227MY
C
ELEC
220UF
20%
6
,
3V
6SVP100M
P
AH
C 0580 VCCCCZ1HH271JY C CERAM 0402 270PF 50V 5% P AA
C 0581 VCKYCZ1HB471KY C CERAM 0402 470PF 50V 10% P AA
C 0582 VCKYCZ1HB471KY C CERAM 0402 470PF 50V 10% P AA
