Sharp LC-40LE732E User Manual

92
LC-40LE732
LC-46LE732
REF No. PARTS DESCRIPTION *
PRICE
CODE
40" CABINET AND MECHANICAL PART LISTING
CODE
1 CCABAC762WJ01 KSͲCABͲALC40LE63*E/730E P
BA
2 CDAIͲA804WJ01 KSͲSTANDLC40LE730E P
BE
3 TLABZC453WJZZ PANELLABEL P
AA
4 DUNTKF915FM11/14 ADJUSTMAINUNITLE732/LGTUNER P
CC
5 GCABAC762WJ1A FRONTCABINET P
ͲͲ
6 GCABBC083WJ1A REARCABINET40LE730LG P
BF
7 GCOVAE259WJ1A ACHOLDERBRACKETPOWERSWITCH P
ͲͲ
8 LANGKD343WJFW VESABRACKET P
AK
9 LANGKD368WJFW PANELBRACKETHOLDER(TOPANDSIDE) P
BB
10 LANGKD369WJFW PANELBRACKETHOLDERBOTTOM P
BC
11 LANGKD370WJFW STANDBRACKET P
BG
11
LANGKD370WJFW
STAND

BRACKET
P
BG
12 LANGKD378WJFW TERMINALCOVERBOTTOM P
AH
13 LANGKD555WJFW CONNECTORSBRACKET40LE732 P
AH
14 LHLDWA048WJKZ WIREHOLDER P
AA
15 LHLDWA303WJKA WIREHOLDER P
AC
16 LHLDZA929WJZZ HOLDER P
AE
17 PZETKA640WJZZ INSULATIONSHEETFORCONTROLLERPWB P
AG
18 PZETKA641WJZZ INSULATIONSHEETFORPANE
L
P
AF
19 PZETKA645WJKZ INSULATIONSHEETPOWER P
AM
20 QCNWͲM004WJQZ CABLE(PD) P
AK
21 310431115371 FFCLVDS51PINS P
AS
22
310431114481
FFC LVDS 41PINS
P
AS
22
310431114481
FFC

LVDS

41PINS
P
AS
23 R1LK400D3LB43A 40"LCDMODULELK400D3LB43A P
DD
24 RCORFA061WJZZ FERRITECORE/CSͲFPCE04FG460812ͲTP
AE
¡
25 RDENCA440WJQZ POWERWITHLEDDRIVER40"LE730 P
BN
26 RSPͲZA594WJZZ SPEAKER6OHm12WFULLRANGETOA/KͲTech P
BA
27 RSPͲZA595WJZZ SPEAKER2x4OHM5WTWEETERTOA/KͲTECH P
AU
28 RUNTKA880WJPA2 CONTROLBUTTONUNITLE730EBLACK P
BC
29 TLABNC117WJZZ ETIQUETAMODELO3M7291ADHESIVOAPͲ360 P
AA
30 TLABZC949WJZZ CEENERGYLABEL P
AH
31 TLABZD050WJZZ POPLABEL P
ͲͲ
32 XBPS730P06000 SCREWPANSTZNM3x6 P
AA
33
XEPS730P08WS0
SCREW PAN ST ZN 3 8
P
AA
33 XEPS730P08WS0 SCREWPANSTZN3x8 P
AA
34 XEPS730P12WS0 SCREWPANSTZN3x12 P
AA
35 XBPS730P06WS0 SCREWPANSTZNM3x6 P
AA
36 QACCKA058WJPZ ACCORDLE730 P
AQ
37 RUNTKA4593TPYA LCDCONTROLETUNIT P
BP
38 LXͲBZA429WJF8 STANDSCREWM4x10BK P
ͲͲ
REF No. PARTS DESCRIPTION *
PRICE
CODE
46" CABINET AND MECHANICAL PART LISTING
CODE
1 CCABAC769WJ01 KSͲCABͲALC46LE63*E P
BD
2 CDAIͲA805WJ01 KSͲSTANDLC46LE730E P
BE
3 DUNTKF915FM11/14 ADJUSTMAINUNITLE732/LGTUNER P
CC
4 GCABAC769WJ1A FRONTCABINET P
BD
5 GCABBC084WJ1A REARCABINET46LE730LG P
BH
6 GCOVAE259WJ1A ACHOLDERBRACKETPOWERSWITCH P
ͲͲ
7 LANGKD343WJFW VESABRACKET P
AK
8 LANGKD369WJFW PANELBRACKETHOLDERBOTTOM P
BC
9 LANGKD373WJFW PANELBRACKETHOLDERTOP P
ͲͲ
10 LANGKD375WJFW STANDBRACKET P
ͲͲ
11 LANGKD378WJFW TERMINALCOVERBOTTOM P
AH
11
LANGKD378WJFW
TERMINAL

COVER

BOTTOM
P
AH
12 LANGKD557WJFW CONNECTORSBRACKET46LE732 P
AH
13 LHLDWA048WJKZ WIREHOLDER P
AA
14 LHLDWA303WJKA WIREHOLDER P
AC
15 LXͲBZA425WJF7 SCREWWASHERM4x8mm.(Silver) P
AA
16 PZETKA640WJZZ INSULATIONSHEETFORCONTROLLER PWB P
AG
17 PZETKA645WJKZ INSULATIONSHEETPOWER P
AM
18 QCNWͲM004WJQZ CABLE(PD) P
AK
19 310431115371 FFCLVDS51PINS P
AS
20 310431114481 FFCLVDS41PINS P
AS
21 R1LK460D3LB33G 46"LCDMODULELK460D3LB33G P
DM
22
RCORFA061WJZZ
FERRITE CORE/CS
Ͳ
FPC E04FG460812
Ͳ
T
P
AE
22
RCORFA061WJZZ
FERRITE

CORE/CS
Ͳ
FPC

E04FG460812
Ͳ
T
P
AE
¡
23 RDENCA440WJQZ POWERWITHLEDDRIVER40"LE730 P
BN
24 RSPͲZA594WJZZ SPEAKER6OHm12WFULLRANGETOA/KͲTech P
BA
25 RSPͲZA595WJZZ SPEAKER2x4OHM5WTWEETERTOA/KͲTECH P
AU
26 RUNTKA880WJPA2 CONTROLBUTTONUNITLE730EBLACK P
BC
27 TLABNC117WJZZ ETIQUETAMODELO3M7291ADHESIVOAPͲ360 P
AA
28 TLABZC453WJZZ PANELLABEL P
AA
29 TLABZD050WJZZ POPLABEL P
ͲͲ
30 TLABZD041WJZZ CEENERGYLABEL P
AH
31 XBPS730P06WS0 SCREWPANSTZNM3x6 P
AA
32 XEPS730P08WS0 SCREWPANSTZN3x8 P
AA
33
XEPS730P12WS0
SCREW PAN ST ZN 3 12
P
AA
33 XEPS730P12WS0 SCREWPANSTZN3x12 P
AA
34 QACCKA058WJPZ ACCORDLE730 P
AQ
35 RUNTK4593TPYB LCDCONTROLERUNIT P
BP
36 LXͲBZA429WJF8 STANDSCREWM4x10BK P
ͲͲ
