LC-40/46/52/60LE835U/830U/832U/LC-60LE831U
4 – 7
2. Removing of Speaker-L/R.
1. Remove the 8 lock screws and detach the Fixing Metal Angle .
2. Detach the Bottom Cover .
3. Disconnect SP wire.
4. Detach the Speaker-L , Speaker-R .
4Speaker-L5Speaker-R
1
3 Bottom Cover
2 Fixing Metal Angle
MAIN Unit
[SP]
[SP]
