LC-40/46/52/60LE835U/830U/832U/LC-60LE831U
4 – 17
2. Removing of Speaker-L/R.
1. Remove the 2 lock screws detach the Bottom Cover .
2. Remove the 19 lock screws and detach the Fixing Metal Angle .
3. Disconnect SP wire.
4. Detach the Speaker-L , Speaker-R .
[SP]
[SP]
5Speaker-L6Speaker-R
3
1
4
Fixing Metal Angle
2 Bottom Cover
MAIN Unit
