Sharp LC-42D64U User Manual

LC-42/46/52D64U
22
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
SG804 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG805 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG806 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG807 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
SG808 RH-VXA187WJQZY AB J Discharge Gap, EZAEG2A50AX
VA801 RH-VXA074WJZZY AB J Varistor, AVRL101A1R1NTB
VA802 RH-VXA074WJZZY AB J Varistor, AVRL101A1R1NTB
[6] DUNTKE264FM02 (R/C, LED Unit)
C102 VCKYTV1CF225ZY AB J Capacitor, 2.2 16V Ceramic
C104 VCEASX1CN106MY AC J Capacitor, 10 16V Electrolytic
C105 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C107 VCEASY1CN107MY AC J Capacitor, 100 16V Electrolytic
D101 RH-EXA092WJZZY AB J Zener Diode, 12V
D103 RH-PX0421CEZZY AD J Photo Diode, CL-165HR/YG-D-T
D114 RH-PX0421CEZZY AD J Photo Diode, CL-165HR/YG-D-T
D115 RH-PX0421CEZZY AD J Photo Diode, CL-165HR/YG-D-T
IC101 VHIGA1S100W-1Y AF X IC, GA1A1S100WP
P101 QPLGNA335WJZZY AD J Plug, 15pin (RA)
Q102 VS2SC3928AR-1Y AB J Transistor, 2SC3928AR
Q103 VS2SC3928AR-1Y AB J Transistor, 2SC3928AR
Q104 VS2SC3928AR-1Y AB J Transistor, 2SC3928AR
Q106 VS2SC3928AR-1Y AB J Transistor, 2SC3928AR
Q107 VS2SC3928AR-1Y AB J Transistor, 2SC3928AR
R101 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R104 VRS-CY1JF273JY AA J Resistor, 27k 1/16W Metal Oxide
R105 VRS-CY1JF393JY AA J Resistor, 39k 1/16W Metal Oxide
R108 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R109 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R117 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R121 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R122 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R123 VRS-CJ1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R124 VRS-CJ1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R135 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Receiver
SLD101 PSLDPA076WJFW AB X Shield Case
[7] DUNTKE266FM02 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode, 15V
D152 RH-EX0646GEZZY AA J Zener Diode, 15V
D155 RH-EX0646GEZZY AA J Zener Diode, 15V
P151 QPLGNA059WJZZ AC J Plug, 5pin (KM)
R151 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch, CH-UP
S152 QSW-K0003AJZZ+ AB J Switch, CH-DOWN
S153 QSW-K0003AJZZ+ AB J Switch, INPUT
S154 QSW-K0003AJZZ+ AB J Switch, VOL-UP
S155 QSW-K0003AJZZ+ AB J Switch, VOL-DOWN
S156 QSW-K0003AJZZ+ AB J Switch, MENU
S157 QSW-K0003AJZZ+ AB J Switch, POWER
[5] DUNTKE209FM01 (SIDE Unit)
