LC-42/46/52D64U
6 – 6
[HDMI signal input] No video (5)
HDMI: No external input video [INPUT-4] HDMI: No external input video [INPUT-5]
Is INPUT-4 selected on the input select menu screen? Is INPUT-5 selected on the input select menu screen?
YES
NO
YES
NO
Select INPUT-4 on the input select menu screen for
the right input signal.
Select INPUT-5 on the input select menu screen for the
right input signal.
Does the HOT PLUG detection function? Does the HOT PLUG detection function?
Does the DDC5V signal come from pin(18) of SC801
to pin(72) of IC1604(HDMI-SW)?
Does the DDC5V signal come from pin(18) of SC1601
to pin(32) of IC1604(HDMI-SW)?
YES
NO
YES
NO
Check the line between the input termi-
nals of SC801 and IC1604.
SC801 pin(18) IC801 pin(39)
SC802 pin(19) SC1603 pin(3)
IC1604 pin(72)
Check the line between the input terminals
of SC1601 and IC1604.
Does the HPD signal come from pin(56) of IC1604 to
pin(19) of SC801?
Does the HPD signal come from pin(16) of IC1604 to
pin(19) of SC1601?
NO
NO
Check the line between IC1604 and
SC801.
IC1604 pin(56) SC1603 pin(4)
SC802 pin(18) IC801 pin(25)
IC807 pin(4) SC801 pin(19)
Check the line between IC1604 and
SC1601.
IC1604 pin(16) IC1607 pin(4)
SC1601 pin(19)
Are there the TMDS signal inputs at pins(27/28)(CLK-/+), (29/30)(D0-/+),
(32/33)(D1-/+), (34/35)(D2-/+), all of IC803?
Are there the TMDS signal inputs at pins(18/19)(CLK-/+), (21/
22)(D0-/+), (24/25)(D1-/+), (27/28)(D2-/+), all of IC1604?
YES
NO
YES
NO
Is IC802(EEPROM) accessed by I2C, with HDMI con-
nected, to read the DDC_I2C SCL/SDA data?
Is IC1601(EEPROM) accessed by I2C, with HDMI con-
nected, to read the DDC_I2C SCL/SDA data?
NO NO
Check the DDC line and its peripheral circuits. (IC801
and its peripherals).
Check the DDC line and its peripheral circuits. (IC1601
and its peripherals).
Are there the TMDS signal inputs at pins(58/59)(CLK-/+), (61/62)(D0-/+),
(64/65)(D1-/+), (67/68)(D2-/+), all of IC1604?
YES
NO
Check the TMDS line between IC803 and IC1604
(SC802 and SC1603, etc.).
Are there the TMDS signal inputs at pins(39/40)(CLK-/+), (43/44)(D0-/+), (47/48)(D1-/+),
(51/52)(D2-/+), all of IC1502(HDMI-Rx)?
NO Check IC1502, IC1604 and their peripheral
circuits.
YES
Are there the HD_DVI[29:0], HD_DVI_CLK_P, HD_DVI_VSYNC, HD_DVI_HSYNC,
HD_DVI_DE signal outputs to IC1502?
NO Check IC1502 and their peripheral circuits.
YES
Are there the HD_DVI[29:0], HD_DVI_CLK_P, HD_DVI_VSYNC, HD_DVI_HSYNC,
HD_DVI_DE signal inputs to IC8001?
NO Check the line between IC1502 and
IC8001.
YES
To Next Page
